Product Introduction
The Yokogawa ADV159-P01 S1 Digital Input Module is a high-quality, high-performance module designed for use in industrial automation and control systems. It is part of the Yokogawa CENTUM CS 3000 and ProSafe-RS product families, offering reliable, precise, and robust signal processing for digital input signals in critical process control environments. This module features enhanced diagnostics, high reliability, and fault-tolerant capabilities, making it ideal for use in industries such as power generation, oil & gas, chemical, and manufacturing.
With 16 digital input channels, the ADV159-P01 S1 provides an efficient interface for monitoring binary (on/off) signals from various field devices, such as limit switches, relays, and sensors. Designed to work seamlessly with Yokogawa’s control systems, this module ensures superior operational stability and easy integration with other process control hardware. It is engineered to meet global industrial standards, including CE, CSA, and ATEX certifications.
Product Specifications
| Parameter | Specification |
|---|---|
| Model | ADV159-P01 S1 |
| Module Type | Digital Input Module |
| Number of Channels | 16 Channels |
| Input Signal Type | Voltage Input (Dry Contact Compatible) |
| Input Voltage Range | 24 V DC nominal (19.2 – 28.8 V DC) |
| Input Resistance | Approx. 4.7 kΩ |
| Signal Delay | Typically 10 ms |
| Isolation | Channel-to-Channel and Channel-to-Ground isolation |
| Connector Type | Removable terminal block |
| Status Indication | LED for each input channel |
| Redundancy | Supports dual-redundant configuration |
| Mounting Type | Rack mount (Yokogawa System Rack) |
| Power Consumption | Approx. 3.5 W |
| Operating Temperature Range | 0°C to 55°C |
| Storage Temperature Range | -20°C to 70°C |
| Humidity Tolerance | 5% to 95% RH, non-condensing |
| Dimensions (H x W x D) | 127.2 × 130 × 32.8 mm |
| Weight | 0.4 kg |
| Compliance Standards | CE, CSA, ATEX, RoHS |
| System Compatibility | CENTUM CS 3000, ProSafe-RS, Vnet/IP systems |
Applications
The ADV159-P01 S1 Digital Input Module is ideal for a wide range of industrial applications that require high-performance digital input monitoring. These applications include, but are not limited to:
-
Oil & Gas: Ensures accurate signal acquisition from field devices like valve positioners, limit switches, and pressure sensors. Used in both upstream and downstream processes such as drilling, refining, and pipeline management.
-
Power Generation: Monitoring and controlling on/off signals for equipment such as turbines, boilers, and circuit breakers, ensuring system stability and operational efficiency.
-
Chemical & Petrochemical: Applied in critical process control systems, including emergency shutdown systems (ESD), safety instrumented systems (SIS), and process monitoring equipment.
-
Water & Wastewater Management: Integrates with pumping stations, level monitoring systems, and water treatment control systems, ensuring proper operation and minimal downtime.
-
Manufacturing Automation: Provides real-time monitoring of assembly lines, automated systems, and robotic processes, ensuring efficient operations and fast fault detection.
-
Pharmaceutical Manufacturing: Helps maintain compliance with regulations by controlling batch processes, ensuring safety and quality in the manufacturing of drugs and medical devices.
Product Advantages
-
High Channel Density: With 16 channels per module, the ADV159-P01 S1 maximizes space efficiency in process control systems without compromising on functionality.
-
Built-in Diagnostics: Each input channel has an individual LED indicator for operational status, allowing easy fault detection and minimizing downtime.
-
Robust and Reliable: Designed for industrial environments, this module is resistant to extreme conditions such as high temperatures, humidity, and electrical interference.
-
Redundancy Support: Dual-redundant configurations ensure continuous operation and fault tolerance, critical in safety-critical applications.
-
Modular Design: The modular nature of the ADV159-P01 S1 allows for easy system expansion and maintenance without requiring complex reconfigurations.
-
Quick Installation and Integration: Compatible with Yokogawa’s CENTUM CS 3000 and ProSafe-RS systems, facilitating seamless integration and fast system setup.
-
Global Certification: The module is certified for use in hazardous locations (ATEX) and meets international standards for electrical and environmental safety.
-
Low Power Consumption: With a power consumption of just 3.5W, the ADV159-P01 S1 contributes to energy-efficient system operation.
-
Environmental Durability: It operates effectively across a wide temperature range (0°C to 55°C) and withstands environmental stress in industrial applications.
Frequently Asked Questions (FAQ)
-
Q: What types of digital signals can the ADV159-P01 S1 module handle?
A: The module supports 24V DC voltage input signals and is compatible with dry contact devices. -
Q: Is this module suitable for use in hazardous areas?
A: Yes, the ADV159-P01 S1 is ATEX certified for use in hazardous locations. -
Q: How many input channels does the ADV159-P01 S1 have?
A: It provides 16 digital input channels. -
Q: Can the module be integrated with systems other than Yokogawa products?
A: While the module is optimized for Yokogawa systems (CENTUM CS 3000 and ProSafe-RS), it can be adapted to other control systems with the appropriate interfaces. -
Q: What is the power consumption of the ADV159-P01 S1?
A: The module consumes approximately 3.5 W of power during operation. -
Q: Can this module be used in high-temperature environments?
A: Yes, the ADV159-P01 S1 can operate in temperatures ranging from 0°C to 55°C. -
Q: Does the ADV159-P01 S1 module have any diagnostic features?
A: Yes, each input channel has an individual LED indicator for real-time status monitoring and fault detection. -
Q: What happens if one input channel fails?
A: Each channel is independently isolated, so a failure on one channel does not affect the others. -
Q: Can the ADV159-P01 S1 module be installed and replaced without shutting down the system?
A: Yes, the module supports hot-swapping, allowing for maintenance without system shutdown. -
Q: What certifications does the ADV159-P01 S1 have?
A: The module is CE, CSA, ATEX, and RoHS certified, ensuring compliance with international safety and environmental standards.
Related Models from the Same Series or Functionality
| Model | Description | Channels | Type | Compatibility |
|---|---|---|---|---|
| ADV151 | Digital Input Module, 16-ch, Basic | 16 | Digital Input | CENTUM CS 3000 |
| ADV151-P01 | Digital Input Module, 16-ch, with Isolation | 16 | Digital Input (Isolated) | ProSafe-RS |
| ADV161 | Digital Input Module, Isolated, 8-ch | 8 | Digital Input (Isolated) | ProSafe-RS |
| ADV541 | Digital Output Module, 16-ch | 16 | Digital Output | CENTUM CS 3000 |
| ADV158 | Digital Input Module, Isolated, 16-ch | 16 | Digital Input (Isolated) | ProSafe-RS |
| ADV159 | Digital Input Module, 16-ch | 16 | Digital Input | CENTUM CS 3000, VP |
Popular Yokogawa Models (Cross-Platform or Widely Used)
| Model | Description | Type | System Compatibility |
|---|---|---|---|
| AAI143-H50 | Analog Input Module, 16-ch, High Speed | Analog Input | CENTUM VP, CS 3000 |
| ADV151 | Digital Input Module, 16-ch | Digital Input | CENTUM CS 3000 |
| AAR145 | Remote I/O Communication Interface Module | Communication Module | ProSafe-RS, CENTUM VP |
| ASB10 | Analog Output Module, 8-ch | Analog Output | CENTUM CS 3000 |
| DI-16/16 | Digital Input Module, Isolated, 16-ch | Digital Input (Isolated) | ProSafe-RS |
| DCS-3200-01 | Controller Unit, Industrial Control System | Controller Unit | CENTUM CS 3000, ProSafe-RS |
