Yokogawa AAP135-S00 S2 Pulse Input Module

Yokogawa/

Yokogawa AAP135-S00 S2 Pulse Input Module

Manufacturer:Yokogawa

Product Number:AAP135-S00 S2

Product Type:Pulse Input Module

Origin:Japan

Dimensions:107.5 × 32.8 × 130 mm

Weight:0.3 kg

Views:14

Payment Methods:T/T, PayPal, Western Union

Condition:New & In Stock

Shipping Port:Xiamen, China

Warranty:1 Year

Lead Time:1-3 Working Days

Certificate:COO

Courier partners:DHL, UPS, TNT, FedEx and EMS.

Business hours:7*24

  • Product Details
  • FAQs
  • Related
  • Contact Us
  • Packing & Delivery
Company Information
E-mail [email protected]
Mobile +8613666084105
Whatsapp +8613666084105
WeChat 13666084105
Add Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Introduction

The Yokogawa AAP135-S00 S2 Pulse Input Module is a high-performance device designed for pulse input measurement in industrial automation and control systems. It is widely used in applications where precise pulse counting or frequency measurement is required. Compatible with Yokogawa’s CENTUM CS 3000 and CENTUM VP distributed control systems (DCS), the AAP135-S00 S2 module supports reliable pulse data acquisition from various sources, such as flow meters, counters, and other frequency-generating devices. Its robustness and versatility make it an ideal solution for applications in sectors like chemical processing, water treatment, and power generation.


Technical Specifications

Parameter Description
Model Number AAP135-S00 S2
Product Type Pulse Input Module
Signal Type Pulse (Frequency input)
Input Range 0 to 10 kHz (varies by configuration)
Input Type Dry contact, open collector, or TTL logic
Number of Channels 8 channels per module
Isolation Electrical isolation between input channels and control system
Power Supply Requirements 24 V DC (±20%)
Operating Temperature -20°C to +60°C
Humidity Range 5% to 95%, non-condensing
Accuracy ±0.1% of full-scale range
Response Time < 5 ms
Dimensions (W x H x D) 107.5 × 32.8 × 130 mm
Weight 0.3 kg
Mounting DIN rail mounting
Certifications CE, UL, RoHS
Signal Conversion Frequency-to-digital conversion
Data Update Period 100 ms

Applications

The AAP135-S00 S2 Pulse Input Module is suited for industrial applications requiring accurate pulse counting and frequency measurement, such as:

  • Flow Measurement: Integrating with flow meters to measure liquid or gas flow in pipelines, where pulse signals are generated by turbine meters or positive displacement flow meters.

  • Water and Wastewater Treatment: Monitoring water flow and level control in treatment plants.

  • Power Generation: Counting revolutions in turbines or pumps, measuring generator output frequencies.

  • Automated Meter Reading (AMR): Collecting pulse data from utility meters such as electricity, gas, or water meters.

  • Batch Process Control: Using pulse data from counters to control material inputs and outputs in chemical processes.

  • Production Line Monitoring: Counting cycles in manufacturing processes to optimize production workflows.


Product Advantages

  • High Accuracy: The AAP135-S00 S2 module ensures high-precision pulse counting with an accuracy of ±0.1%, which is essential for reliable process control.

  • Wide Input Range: Supports a broad frequency input range from 0 to 10 kHz, making it adaptable to different types of industrial pulse sources.

  • Multiple Channel Support: Can handle up to 8 channels per module, providing flexibility for applications requiring multiple signal inputs.

  • Electrical Isolation: Offers complete isolation between input channels and the control system, minimizing the risk of interference and ensuring stable operation.

  • Compact Design: The module’s small form factor allows for easy installation on DIN rails, saving valuable panel space.

  • Temperature and Humidity Resilience: With an operating temperature range of -20°C to +60°C, it is suitable for harsh industrial environments.

  • Low Power Consumption: Designed to operate on a 24 V DC supply, making it energy efficient for continuous operation in large-scale systems.

  • Easy Integration: Fully compatible with Yokogawa’s CENTUM CS 3000 and CENTUM VP systems, ensuring seamless integration into existing control systems.

  • Quick Data Update: Features a rapid data update period (100 ms), ensuring real-time monitoring and control.


Frequently Asked Questions (FAQ)

  1. What types of pulse inputs does the AAP135-S00 S2 module support?
    The module supports dry contact, open collector, or TTL logic pulse inputs.

  2. What is the maximum input frequency the module can handle?
    The module can handle frequencies up to 10 kHz, depending on configuration.

  3. Can the module be used in hazardous environments?
    While the module has CE and UL certifications, additional protective measures may be required for hazardous environments.

  4. How many channels does the module support?
    The module supports up to 8 channels, allowing for multiple pulse inputs.

  5. What is the accuracy of the pulse counting?
    The accuracy of the module is ±0.1% of the full-scale range.

  6. What is the response time of the module?
    The response time of the module is less than 5 milliseconds.

  7. What is the operating temperature range?
    The module can operate in environments ranging from -20°C to +60°C.

  8. Can the module be mounted on a standard DIN rail?
    Yes, the module is designed for easy mounting on a standard DIN rail.

  9. What is the power supply requirement for the module?
    The module requires a 24 V DC power supply with a tolerance of ±20%.

  10. Is the AAP135-S00 S2 module compatible with other Yokogawa systems?
    Yes, it is compatible with Yokogawa’s CENTUM CS 3000 and CENTUM VP systems.


Related Models (Same Series or Functionally Similar)

Model Number Description Input Type Number of Channels System Compatibility
AAP132-S00 S2 Frequency Input Module Pulse (Frequency input) 4 CENTUM VP / CS 3000
AAP133-S00 S2 Pulse Input Module Pulse (TTL/Open collector) 8 CENTUM CS 3000
AAP134-S00 S2 High-Accuracy Pulse Input Module Pulse (Frequency input) 8 CENTUM VP
AAP137-S00 Digital Input Module Digital (Discrete) 4 or 8 CENTUM CS 3000
AAP138-S00 High-Speed Pulse Input Module Pulse (TTL/Open collector) 16 CENTUM VP
AAP139-S00 Frequency/Phase Input Module Pulse (Frequency/Phase) 8 CENTUM CS 3000, CENTUM VP

Popular Yokogawa Models (Same Brand, High Market Usage)

Model Number Description Module Type System/Application Notable Features
YTA320 Temperature Transmitter Field Instrument Temperature Measurement Dual input, HART protocol
EJA530E Pressure Transmitter Field Instrument Process Measurement High accuracy, SIL-certified
FA-M3R Programmable Logic Controller (PLC) Control Module Discrete & Batch Process Control High-speed scanning
ADM52-S1 Analog Input Module Input Module DCS (CENTUM VP) High channel accuracy
AQM21 Air Quality Monitor Environmental Monitoring Smart city / Factory emissions PM2.5, CO2, VOCs monitoring
YHC5150X HART Communicator Handheld Communicator Field Device Configuration Universal HART protocol support
