Product Introduction
The Yokogawa AAI543-S00/A4S00 Analog Output Module is a high-performance module designed for use in industrial automation systems, specifically for controlling output signals in process control and instrumentation applications. This module is a part of Yokogawa’s AAM Series and is widely used in Distributed Control Systems (DCS), programmable logic controllers (PLC), and other advanced industrial systems. The AAI543-S00/A4S00 provides high-precision, reliable analog signal outputs for a wide range of industrial processes, helping improve the overall performance of the automation system.
This module features four analog output channels, providing 4-20 mA and 0-10 V signals to control instruments, valves, and other equipment. The module is known for its high reliability, precision, and ease of integration with existing Yokogawa systems. Its compact design and high-speed processing make it suitable for demanding control applications where accuracy and stability are critical.
The AAI543-S00/A4S00 module is designed with high-quality components that ensure a long service life even in harsh industrial environments. It is ideal for applications where output signal precision and long-term reliability are required, such as in the chemical, oil and gas, power generation, and manufacturing industries.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | AAI543-S00/A4S00 |
| Module Type | Analog Output Module |
| Channels | 4 Analog Output Channels |
| Output Type | 4-20 mA, 0-10 V |
| Signal Accuracy | ±0.1% of Full Scale (FS) |
| Resolution | 16-bit |
| Power Supply | 24 V DC ±20% |
| Isolation | Channel-to-Channel Isolation: 250 V AC |
| Temperature Range | Operating: -20°C to +60°C |
| Storage: -40°C to +85°C | |
| Response Time | <10 ms (for 0-100% change in output) |
| Dimensions (H x W x D) | 107.5 × 32.8 × 130 mm |
| Weight | 0.4 kg |
| Mounting Type | DIN Rail |
| Compliance | CE, UL, RoHS |
| Certification | Ex-approved versions available upon request |
| Input/Output Connection | Screw Terminal or Spring Terminal Options |
Product Applications
The Yokogawa AAI543-S00/A4S00 Analog Output Module is primarily used for controlling field devices and actuators that require precise, reliable analog signals. Its wide range of applications includes:
-
Process Control Systems: In industries such as oil and gas, chemicals, pharmaceuticals, and food and beverage, it controls processes like pressure, flow, temperature, and level by generating accurate analog signals to control pumps, valves, and other equipment.
-
Environmental Monitoring: Used to interface with environmental sensors that measure parameters like temperature, humidity, and gas concentration, sending these measurements to central systems for analysis.
-
Building Automation Systems: Controls heating, ventilation, and air conditioning (HVAC) systems, adjusting airflow and temperature settings based on feedback from sensors.
-
Energy and Utilities: Essential in power plants for controlling the operation of turbines, motors, and other critical machinery through precise analog outputs.
-
Industrial Automation: Widely deployed in automation lines and manufacturing systems where controlling machinery with analog signals is necessary for system optimization.
Product Advantages
-
High Accuracy and Reliability: The AAI543-S00/A4S00 ensures precision in delivering analog output signals, which is crucial for maintaining the stability and efficiency of industrial processes.
-
Fast Response Time: The module features a quick response time of less than 10 milliseconds, enabling real-time control adjustments without delay.
-
Compact and Space-Efficient: Its compact size allows for installation in systems with limited space, making it perfect for applications with stringent space requirements.
-
Versatile Output Options: The module supports both current (4-20 mA) and voltage (0-10 V) outputs, offering flexibility for a wide range of field instruments.
-
High Channel Isolation: With excellent channel-to-channel isolation of up to 250 V AC, the module ensures stable operation even in electrically noisy environments.
-
Durable and Robust Design: Built to withstand harsh environmental conditions such as extreme temperatures and industrial vibrations, the AAI543-S00/A4S00 is designed to last in tough operational settings.
-
Easy Integration: Fully compatible with Yokogawa DCS, PLC, and SCADA systems, ensuring seamless integration and reducing setup time.
Frequently Asked Questions (FAQ)
-
Q: What is the maximum number of output channels on the AAI543-S00/A4S00 module?
A: The module has 4 analog output channels. -
Q: What types of analog output signals does this module support?
A: It supports 4-20 mA and 0-10 V output signals. -
Q: What is the accuracy of the output signals?
A: The module provides an accuracy of ±0.1% of Full Scale (FS). -
Q: Can I use this module in high-temperature environments?
A: Yes, the module operates in temperatures ranging from -20°C to +60°C. -
Q: What is the power supply requirement for the AAI543-S00/A4S00 module?
A: It requires a 24 V DC ±20% power supply. -
Q: How is this module mounted?
A: The module is designed for DIN rail mounting. -
Q: What is the response time for changes in output?
A: The response time is less than 10 milliseconds for a 0-100% change in output. -
Q: Is the module isolated between output channels?
A: Yes, the module has excellent channel-to-channel isolation, with up to 250 V AC isolation. -
Q: Does the module meet environmental compliance standards?
A: Yes, it is CE and RoHS certified and complies with international standards. -
Q: Can the module handle harsh electrical environments?
A: Yes, it has been designed with high isolation and protection against electrical interference, making it suitable for noisy environments.
