Product Introduction
The Yokogawa AAI143-S00 Analog Input Module is part of Yokogawa’s Centum VP distributed control system (DCS) series. This module is designed to provide highly accurate, reliable, and high-speed analog signal input for industrial process control applications. It supports the input of analog signals such as temperature, pressure, and flow from a wide variety of industrial instruments. This input module is ideal for chemical, petrochemical, energy, and manufacturing sectors where precise and stable control is paramount.
The AAI143-S00 module is designed to integrate easily into Yokogawa’s automation systems, supporting both 4-20mA and 0-10V signal types. Its high-resolution analog-to-digital conversion ensures minimal signal degradation, offering precision in real-time process monitoring and control. With its modular design, the AAI143-S00 can be expanded and customized according to process requirements.
Product Specifications
| Parameter | Specification |
|---|---|
| Model | AAI143-S00 |
| Type | Analog Input Module |
| Number of Channels | 8 channels |
| Input Signal Types | 4-20mA, 0-10V |
| Resolution | 16-bit |
| Input Impedance | 250 Ohms (for 4-20mA signals) |
| Accuracy | ±0.1% of Full Scale |
| Signal Conversion | 16-bit A/D conversion |
| Communication Interface | Fieldbus / Yokogawa proprietary protocol |
| Operating Temperature | -10°C to 60°C |
| Storage Temperature | -20°C to 70°C |
| Power Supply | 24V DC |
| Power Consumption | 6W |
| Dimensions (L x W x H) | 107.5 × 32.8 × 130 mm |
| Weight | 0.3 kg |
| Mounting Type | DIN Rail Mountable |
| Certifications | CE, UL, Ex (ATEX) |
| Environmental Protection | IP20 |
Product Applications
The Yokogawa AAI143-S00 Analog Input Module is typically used in industries that demand high precision and reliability in their analog data acquisition. Common applications include:
-
Process Automation Systems:
The AAI143-S00 is widely used in DCS systems to collect analog data such as temperature, pressure, and flow rate from process instruments. It provides real-time data that is essential for continuous process control. -
Chemical and Petrochemical Industries:
The module is used to measure variables like flow, pressure, and level in pipelines and vessels, ensuring smooth and safe operation. -
Power Generation:
It is used in monitoring critical parameters in power plants, including boiler temperatures, turbine pressures, and fuel flow rates. -
Oil & Gas:
In the upstream and downstream sectors, the AAI143-S00 ensures safe and effective monitoring of various process parameters in refinery operations. -
Water Treatment and Wastewater Management:
The module is ideal for monitoring parameters such as pH, turbidity, and level in water treatment plants. -
Manufacturing & Industrial Automation:
It provides crucial input for systems that control industrial machinery, monitoring machine temperatures, humidity, and pressure for optimal performance. -
HVAC Systems:
Used in heating, ventilation, and air conditioning systems for monitoring temperature and humidity.
Product Advantages
1. High Accuracy and Reliability
The Yokogawa AAI143-S00 provides ±0.1% accuracy, ensuring that data from sensors and process instruments is reliable and precise, which is critical for high-precision industrial applications.
2. Wide Signal Compatibility
It supports 4-20mA and 0-10V input signals, making it versatile and compatible with most analog devices and sensors commonly used in industrial processes.
3. Easy Integration with DCS
Designed to integrate seamlessly into Yokogawa’s Centum VP DCS, it simplifies the setup of complex control systems while ensuring smooth communication with the broader control network.
4. Modular Design for Scalability
The modular design of the AAI143-S00 allows easy expansion of the system, making it flexible for various types of applications and future upgrades.
5. Excellent Environmental Protection
With IP20 protection and a wide operating temperature range of -10°C to 60°C, it is well-suited for industrial environments, offering durability and stability in harsh conditions.
6. Low Power Consumption
With a 6W power consumption, this module is energy-efficient, contributing to cost savings in industrial operations.
7. Quick Installation and Setup
This module can be easily mounted on a DIN rail, allowing quick and hassle-free installation in control cabinets and other setups.
Latest News Titles
- Yokogawa Expands Analog Input Module Portfolio with AAI143-S00 for Enhanced Process Control
- Precision and Reliability: The Yokogawa AAI143-S00 Analog Input Module in Industrial Automation
- Yokogawa Introduces AAI143-S00 Analog Input Module with Unmatched Accuracy and Versatility
- Optimizing Process Control with the Yokogawa AAI143-S00 Analog Input Module
- Yokogawa Enhances Distributed Control Systems with New AAI143-S00 Input Module
- The Role of Yokogawa AAI143-S00 in Petrochemical Plant Safety and Efficiency
- Yokogawa’s Latest Analog Input Module Meets the Demands of Modern Power Generation
- Boosting Industrial Automation with the Yokogawa AAI143-S00 Module
- Maximizing Precision with Yokogawa’s AAI143-S00 Analog Input Technology
- Yokogawa AAI143-S00: The Ideal Solution for Water Treatment Plants
Frequently Asked Questions (FAQ)
-
What is the Yokogawa AAI143-S00 used for?
- The AAI143-S00 is an analog input module used in industrial automation systems to measure and convert analog signals such as temperature, pressure, and flow.
-
What input signals are supported by the AAI143-S00?
- It supports 4-20mA and 0-10V input signals.
-
What is the accuracy of the AAI143-S00?
- The module has an accuracy of ±0.1% of full scale.
-
What is the power consumption of the AAI143-S00?
- The module consumes 6W of power.
-
How many channels does the AAI143-S00 have?
- It has 8 channels for analog input.
-
What is the operating temperature range for this module?
- The module operates between -10°C and 60°C.
-
Is this module compatible with other Yokogawa automation systems?
- Yes, the AAI143-S00 is designed for seamless integration with Yokogawa Centum VP DCS.
-
What are the physical dimensions of the module?
- The dimensions are 107.5 × 32.8 × 130 mm.
-
How does the module handle signal conversion?
- The AAI143-S00 uses 16-bit analog-to-digital conversion for accurate data processing.
-
Is the AAI143-S00 suitable for use in hazardous environments?
- Yes, it has Ex (ATEX) certifications, making it suitable for hazardous industrial environments.
Related Models within the Same Series
| Model | Type | Channels | Input Signal Types | Special Features |
|---|---|---|---|---|
| AAI141-S00 | Analog Input Module | 16 | 4-20mA | Standard analog input |
| AAI142-S00 | Analog Input Module | 8 | 0-10V | High-speed conversion |
| AAI143-H00 | Analog Input Module | 16 | 4-20mA | High-density input |
| AAI144-S00 | Analog Input Module | 8 | Thermocouple, RTD | Temperature measurement |
| AAI145-S00 | Analog Input Module | 8 | 4-20mA, 0-10V | High-precision input |
| AAI835-H00 | Analog Input Module | 16 | 4-20mA | High-density, HART communication |
| AAI841-H00 | Analog Input Module | 8 | 4-20mA | Isolated channels |
| AAI543-S00 | Analog Input Module | 8 | 4-20mA, 0-10V | Universal input |
| AAI841-S00 | Analog Input Module | 8 | 4-20mA | Isolated channels |
| AAI835-S00 | Analog Input Module | 16 | 4-20mA | High-density input |
