Product Introduction
The Schneider TSXETY4103 Ethernet TCP/IP Module is a communication module designed for use with Schneider Electric’s Modicon Premium PLC series. This module allows seamless integration of Ethernet-based communication, enabling Modicon PLCs to interact with other devices and control systems over a network. With its 10/100 Mbps Ethernet capability, the TSXETY4103 supports reliable and high-speed communication for industrial automation applications.
It is particularly useful in environments where fast, reliable communication between machines and control systems is critical. The module is designed to connect Modicon PLCs to Ethernet networks, allowing for remote monitoring, control, and diagnostics. As part of Schneider Electric’s series of Ethernet communication modules, the TSXETY4103 ensures scalability, flexibility, and ease of integration into complex automation systems.
Product Parameters
The Schneider TSXETY4103 Ethernet TCP/IP Module offers various technical specifications designed for industrial automation systems. Below is a detailed overview of its key parameters:
| Parameter | Value |
| Ethernet Communication | 10/100 Mbps TCP/IP |
| Protocol Supported | Modbus TCP |
| Network Interface | RJ45 connector, Ethernet |
| Power Consumption | 2.5W (typical) |
| Dimensions (LxWxH) | 55 × 180 × 260 mm |
| Weight | 0.34 kg |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -25°C to 70°C |
| Humidity | 5% to 95% RH, non-condensing |
| Mounting | DIN Rail |
Product Applications
The Schneider TSXETY4103 Ethernet TCP/IP Module is designed for use in a wide variety of industrial automation applications. Some of its primary uses include:
-
Industrial Automation: Connecting Modicon PLCs to Ethernet-based control systems for data exchange and monitoring.
-
SCADA Systems: Facilitating communication between PLCs and SCADA systems for real-time process control and data acquisition.
-
Remote Monitoring: Enabling remote access to PLCs for troubleshooting, configuration, and maintenance via Ethernet networks.
-
Data Logging: Transmitting real-time data from PLCs to centralized databases for analysis, reporting, and visualization.
-
Integration with IoT: Seamlessly integrating with Internet of Things (IoT) platforms for enhanced system monitoring and control.
Product Advantages
The Schneider TSXETY4103 Ethernet TCP/IP Module provides several key benefits to users:
-
High-Speed Communication: With 10/100 Mbps Ethernet support, it provides reliable and fast data transmission, ensuring real-time communication across devices.
-
Ease of Integration: The module supports Modbus TCP, a widely-used industrial protocol, making it easy to integrate with other industrial devices and control systems.
-
Compact Design: Its small form factor (90mm x 45mm x 110mm) makes it ideal for installation in limited spaces while maintaining a robust performance.
-
Remote Access: Facilitates remote diagnostics, monitoring, and maintenance, reducing downtime and increasing operational efficiency.
-
Flexibility: Can be used in a variety of industrial applications, from factory automation to energy management systems.
-
Reliability: Built to withstand harsh industrial environments with a wide operating temperature range and robust construction.
