Product Introduction

The Schneider Electric TSXETY4102 is an Ethernet TCP/IP communication module designed for the Modicon Premium PLC series. It facilitates seamless integration of PLCs into Ethernet networks, enabling real-time data exchange and remote monitoring. This module supports multiple protocols, including Modbus TCP, Ethway, and Uni-Telway, ensuring compatibility with various industrial communication standards.

---

Technical Specifications

Parameter	Description
Product Model	TSXETY4102
Product Type	Ethernet TCP/IP Communication Module
Supported Protocols	Modbus TCP, Ethway, Uni-Telway
Maximum Connections	64
Web Server	Transparent Ready Class B30
Data Rate	10/100 Mbps
Power Consumption	800 mA at 5 VDC
Connector Type	RJ45
Mounting Type	Rack-mounted (TSX Premium Series)
Dimensions (L x W x H)	55 × 180 × 260 mm
Weight	0.5 kg
Operating Temperature Range	0°C to +60°C
Storage Temperature Range	-25°C to +85°C
Certifications	CE, UL, CSA, RoHS



---

Applications

The TSXETY4102 module is widely used across various industries that require reliable Ethernet communication, including:

• Manufacturing Automation: Integrating PLCs with SCADA systems for real-time monitoring and control.

• Process Industries: Facilitating data exchange between control systems and field devices.

• Building Management Systems: Enabling centralized control of HVAC, lighting, and security systems.

• Water and Wastewater Treatment: Monitoring and controlling treatment processes remotely.

• Energy Management: Collecting and analyzing data from various energy meters and devices.

Its robust design and compatibility with multiple protocols make it suitable for diverse industrial communication needs.

---

Product Advantages

• Multi-Protocol Support: Ensures compatibility with various industrial communication standards.

• High Connection Capacity: Supports up to 64 simultaneous connections, facilitating extensive network integration.

• Integrated Web Server: Allows for remote diagnostics and monitoring via standard web browsers.

• Robust Design: Built to withstand industrial environments with a wide operating temperature range.

• Seamless Integration: Easily integrates into existing TSX Premium PLC systems without extensive modifications.

---
