Product Introduction
The Schneider BMXMSP0200 Pulse Train Output Module is designed for controlling pulse-based output signals in various industrial automation and control applications. It provides precise control over the output signals, which can be used in a wide range of systems that require pulse trains for driving motors, actuators, or other devices that need time-based control. The module is a part of Schneider Electric’s Modicon series and is known for its high reliability and flexibility in pulse-based control applications.
Product Specifications
| Parameter | Description |
|---|---|
| Model Number | BMXMSP0200 |
| Module Type | Pulse Train Output Module |
| Number of Outputs | 2 Pulse Train Outputs |
| Output Frequency | 1 Hz to 1 MHz |
| Output Resolution | 1 Hz |
| Power Supply | 24V DC |
| Dimensions (W x H x D) | 93 x 33 x 104 mm |
| Weight | 0.145 kg |
| Output Signal | Pulse Train (Square Wave) |
| Compatibility | Modicon M340, M580 |
| Environmental Conditions | Operating Temperature: -20°C to 60°C; Storage Temperature: -40°C to 85°C |
Product Applications
The Schneider BMXMSP0200 Pulse Train Output Module is ideal for:
-
Motion Control Systems: Used in controlling stepper motors or DC motors, where pulse signals regulate position, speed, and acceleration.
-
Automated Manufacturing Systems: For applications requiring precise timing and output, such as controlling rotary or linear actuators.
-
Industrial Automation: The module is used in various types of machinery that require pulse-based signals to drive their operations, such as conveyor systems, robotic arms, and packaging machines.
-
Process Control: In processes where pulse trains control fluid flow, air pressure, or other critical parameters in real-time.
Product Advantages
-
High Output Accuracy: The module ensures high-precision output pulse trains, which are essential for controlling time-sensitive processes in industries like manufacturing and robotics.
-
Wide Frequency Range: With an output frequency range from 1 Hz to 1 MHz, it is adaptable to a variety of different applications.
-
Compatibility with Modicon Series: Seamlessly integrates with Modicon M340 and M580 controllers, making it a reliable choice for existing systems.
-
Compact Design: Its compact form factor allows easy installation in space-constrained environments.
-
Durability: Built to withstand harsh industrial environments, ensuring longevity and reliability under continuous use.
-
Easy Integration: The module supports straightforward integration into Schneider Electric’s modular automation platforms.
