Product Overview

The Invensys Triconex 3451 Relay Output Module is a critical component of the Triconex Safety Instrumented System (SIS), designed to provide high-reliability relay outputs for industrial automation and safety applications. This module ensures precise control over processes, contributing to the safe and efficient operation of industrial systems. It is particularly suitable for applications where safety and reliability are paramount, such as oil and gas, chemical processing, power generation, and water and wastewater treatment.

Product Specifications

Feature	Specification
Model Number	3451
Number of Channels	32, commoned in pairs
Contact Type	Solid-State Relay
Nominal Input Voltage	+24 V
Operational Voltage Range	Up to +30 V
Maximum Switching Voltage	+33 V peak
Maximum Switching Power	12 W
Maximum Off-State Leakage	<100 μA
Nominal Current per Channel	0.5 A
Maximum Overcurrent per Channel	0.7 A
Voltage Drop at Baseplate	<0.25 V at 0.5 A
Fuses	Mounted on the baseplate, 1 per output, 0.75 A, fast-acting
Dimensions	150 x 130 x 50 mm
Weight	0.85 kg
Operating Temperature	0°C to 55°C
Relative Humidity	5% to 95% (non-condensing)

Product Applications

The Triconex 3451 Relay Output Module is utilized across various industries that require high levels of safety and reliability in their control systems. Key applications include:

• Oil & Gas Industry: Used in drilling, production, and refining processes to ensure safe operations and compliance with regulatory requirements.
• Chemical Processing: Integral to monitoring and controlling chemical reactions, ensuring processes remain within safe operational limits.
• Power Generation: Employed in critical control loops, including turbine protection and emergency shutdown systems.
• Water and Wastewater Treatment: Ensures the safe and efficient operation of treatment processes, protecting public health and the environment.

Product Advantages

• High Reliability and Efficiency: Ensures the safe and smooth operation of industrial processes with superior performance and reliability.
• Three-Mode Redundancy (TMR) Architecture: Provides increased system availability and fault tolerance, enhancing overall system safety.
• High-Speed Processing: Capable of handling real-time and mission-critical applications, ensuring timely response to process changes.
• Energy Efficiency: Low power consumption contributes to overall operational cost savings.
• Compact Design: Facilitates easy integration into existing systems without requiring significant space.
