Product Introduction
The CC-PPIX01 module from Honeywell is part of the company’s Series C product line, specifically designed for handling pulse signals in industrial applications. By converting pulse input into measurable data, the module facilitates seamless integration between field devices and control systems. This module is particularly useful in applications where accurate counting and monitoring of processes are crucial, such as flow measurement, energy consumption tracking, and machine operation monitoring.
Designed for reliability and flexibility, the CC-PPIX01 Pulse Input Module supports multiple input configurations, ensuring that it can be easily tailored to meet specific application needs. It is compatible with Honeywell’s control systems and can be used in both large and small-scale industrial environments.
Technical Specifications
Here are the detailed technical specifications for the Honeywell CC-PPIX01 51410089-175 Pulse Input Module:
| Specification | Details |
| Manufacturer | Honeywell |
| Product Number | 51410089-175 / CC-PPIX01 |
| Module Type | Pulse Input Module |
| Input Type | Pulse input from field devices |
| Max Input Frequency | 50 kHz |
| Number of Channels | 4 channels |
| Input Voltage | 24 VDC |
| Input Current | 50 mA per channel |
| Isolation | Galvanic isolation between channels |
| Operating Temperature | -20°C to 60°C (ambient temperature) |
| Storage Temperature | -40°C to 85°C |
| Humidity Range | 5% to 95% non-condensing |
| Dimensions (W x H x D) | 63.5 x 124.46 x 307.34 mm |
| Weight | 0.299 kg |
| Certifications | CE, UL, ATEX |
| Mounting | DIN rail mounting |
Applications
The Honeywell CC-PPIX01 Pulse Input Module is ideal for a range of industrial applications where accurate pulse counting and data acquisition are needed. Some key applications include:
-
Flow Measurement: The module is used to interface with flow meters to accurately measure and record fluid or gas flow in pipelines, tanks, and other industrial systems.
-
Energy Monitoring: It allows for tracking energy consumption in power generation, manufacturing plants, and other energy-intensive industries.
-
Machine Operation Monitoring: The module can interface with machines that generate pulse signals, enabling real-time monitoring of machine performance and status.
-
Process Control: It helps in controlling processes that depend on discrete events, such as counting parts on a production line or monitoring production rates.
Advantages
The Honeywell CC-PPIX01 Pulse Input Module offers several advantages that make it a valuable addition to any industrial control system:
-
High Frequency Handling: With the ability to handle input frequencies up to 50 kHz, the module is suitable for high-speed applications such as high-precision flow measurement and energy tracking.
-
Multi-channel Capability: The module supports up to 4 channels, allowing multiple pulse input signals to be processed simultaneously, enhancing system efficiency.
-
Galvanic Isolation: The galvanic isolation between channels prevents interference from noise or voltage spikes, ensuring reliable operation even in electrically noisy environments.
-
Wide Operating Range: The module operates in a wide temperature range of -20°C to 60°C, making it suitable for use in diverse industrial environments, from cold storage facilities to high-temperature industrial plants.
-
Compact Design: With its small form factor (63.5 x 124.46 x 307.34 mm) and lightweight design (0.299 kg), the module can be easily installed and integrated into control panels or systems.
-
Durable and Safe: The CC-PPIX01 meets several international certifications such as CE and UL, ensuring it meets rigorous safety and quality standards for industrial environments.
Latest News
As of early 2025, the Honeywell CC-PPIX01 Pulse Input Module has gained recognition in industries like oil & gas, chemical processing, and manufacturing for its high accuracy and flexibility in pulse signal processing. Industry experts have highlighted its role in improving operational efficiency and monitoring in process control systems.
For more information, Honeywell’s website provides additional case studies and customer testimonials showcasing how the module is being used to enhance industrial operations in various sectors.
Frequently Asked Questions (FAQs)
-
What is the primary function of the Honeywell CC-PPIX01 module?
-
The CC-PPIX01 is designed to process pulse signals from field devices such as flow meters and counters, converting these pulses into measurable data for control systems.
-
-
How many channels does the CC-PPIX01 support?
-
The module supports up to 4 channels, allowing multiple pulse signals to be processed simultaneously.
-
-
What is the maximum input frequency that the module can handle?
-
The CC-PPIX01 can handle input frequencies up to 50 kHz, making it suitable for high-speed applications.
-
-
What is the operating temperature range for the module?
-
The module operates in a temperature range of -20°C to 60°C, making it suitable for most industrial environments.
-
-
What is the weight of the Honeywell CC-PPIX01 module?
-
The CC-PPIX01 weighs 0.299 kg.
-
-
Can the CC-PPIX01 module be mounted on a DIN rail?
-
Yes, the module is designed for DIN rail mounting, making it easy to integrate into control systems.
-
-
What type of certification does the CC-PPIX01 have?
-
The module is certified for CE, UL, and ATEX standards, ensuring safety and quality for industrial applications.
-
-
How does the module handle electrical isolation?
-
The CC-PPIX01 provides galvanic isolation between channels to prevent interference and ensure reliable operation in electrically noisy environments.
-
-
What types of applications is the CC-PPIX01 suitable for?
-
It is suitable for applications like flow measurement, energy monitoring, machine operation monitoring, and process control.
-
-
Is the module compatible with Honeywell’s control systems?
-
Yes, the CC-PPIX01 is fully compatible with Honeywell’s control systems, allowing seamless integration into existing industrial automation setups.
