Product Introduction
The Honeywell CC-PDIH01 51405041-175 is a high-voltage digital input module designed for the Experion Process Knowledge System (PKS) Series C platform. It provides 16 isolated high-voltage inputs for monitoring the on/off status of field devices. The module accepts inputs from 24 to 250 VAC or 24 to 300 VDC, making it suitable for a wide range of industrial applications. With a response time of less than 1 millisecond and an accuracy of 0.1%, the CC-PDIH01 ensures precise and timely data acquisition. It is certified for use in hazardous areas, including Class I, Division 2, Groups A, B, C, and D, as well as Class II, Division 1, Groups E, F, and G.
Product Specifications
| Parameter | Details |
| Model Number | CC-PDIH01 |
| Part Number | 51405041-175 |
| Input Voltage Range | 24 to 250 VAC / 24 to 300 VDC |
| Number of Inputs | 16 isolated channels |
| Response Time | <1 millisecond |
| Accuracy | ±0.1% |
| Operating Temperature | -40°C to +70°C |
| Mounting | DIN rail or standard 19-inch rack |
| Dimensions | 63.5 x 124.46 x 307.34 mm |
| Weight | 6.8 kg |
| Certifications | Class I, Div 2, Groups A-D; Class II, Div 1, Groups E-G |
| Power Supply | 24 VDC, 60 W |
| Compatibility | Experion PKS Series C |
Product Applications
The CC-PDIH01 module is ideal for monitoring digital signals in various industrial settings, including:
-
Oil and gas facilities
-
Chemical processing plants
-
Power generation stations
-
Water and wastewater treatment plants
-
Pharmaceutical manufacturing
-
Food and beverage processing
-
Pulp and paper mills
Product Advantages
-
High Voltage Input Range: Supports a wide range of input voltages, enhancing versatility.
-
Fast Response Time: Ensures timely detection of input signal changes.
-
High Accuracy: Provides precise input signal measurements.
-
Isolated Channels: Each input channel is electrically isolated, improving system reliability.
-
Hazardous Area Certification: Suitable for use in environments with explosive gases or dust.
-
Compact Design: Space-saving form factor facilitates easy installation.
-
Robust Construction: Designed to withstand harsh industrial conditions.
Recent News Headlines
-
“Honeywell Enhances Experion PKS with Advanced Digital Input Modules”
-
“CC-PDIH01 Module Gains Recognition for Reliability in Harsh Environments”
-
“New High-Voltage Input Module from Honeywell Improves Process Monitoring”
Frequently Asked Questions (FAQ)
-
What is the primary function of the CC-PDIH01 module?
-
It monitors high-voltage digital input signals from field devices.
-
-
What input voltage ranges does the module support?
-
It accepts 24 to 250 VAC or 24 to 300 VDC inputs.
-
-
How many input channels are available?
-
The module provides 16 isolated input channels.
-
-
Is the module suitable for hazardous environments?
-
Yes, it is certified for use in Class I, Division 2, Groups A-D, and Class II, Division 1, Groups E-G areas.
-
-
What is the response time of the module?
-
It has a response time of less than 1 millisecond.
-
-
Can the module be mounted on a DIN rail?
-
Yes, it supports DIN rail and standard 19-inch rack mounting.
-
-
What is the operating temperature range?
-
The module operates between -40°C and +70°C.
-
-
Is the module compatible with other Honeywell systems?
-
It is designed for use with the Experion PKS Series C platform.
-
-
What certifications does the module have?
-
It is certified for hazardous area use as specified above.
-
-
What is the power supply requirement?
-
The module requires a 24 VDC power supply and consumes 60 W.
-
Related Models (Same Series / Similar Functionality)
| Model Number | Description | Module Type | Key Features |
| CC-PDIL01 | Digital Input Module | Digital Input (Low V) | 24VDC input support, isolated channels |
| CC-PDOH01 | Digital Output Module | Digital Output (High V) | Controls high-voltage devices |
| CC-PDOB01 | Digital Output Module | Digital Output (Relay) | Relay-based output module |
| CC-PAIH01 | Analog Input Module | Analog Input | High-resolution analog signal monitoring |
| CC-PAOH01 | Analog Output Module | Analog Output | Precise analog control signals |
| CC-TDIL01 | Digital Input Module | Digital Input | Redundant fieldbus-supported input |
| CC-TAIX01 | Analog Input Module | Analog Input | Thermocouple & RTD input support |
| CC-PAIN01 | Universal Analog Input Module | Universal Input | Supports current, voltage, RTDs, thermocouples |
Popular Honeywell Models (Same Brand – Cross Product Range)
| Model Number | Description | Category | Applications |
| C300 Controller | Process Automation Controller | Controller | Core of Experion PKS for control strategies |
| FTA-PSU240V | Power Supply Unit for I/O Modules | Power Supply | Powers Field Termination Assemblies |
| MC-TDOY22 | Digital Output Module | Safety System Module | TDC3000/TPS safety and shutdown systems |
| MC-PDOY22 | Digital Output Module | Safety System Module | Supports SIL-rated output systems |
| TC-IAH061 | Analog Input Module | TDC2000/TDC3000 | Legacy system input interface |
| 8U-TDODA1 | Digital Output Module | Universal I/O Module | Compatible with ControlEdge PLCs |
| FC-SDI-1624 | Digital Input Module | Safety I/O | SIL 2/3 support, HIMA/Triconex alternative |
| MU-TDID12 | Digital Input Module | TDC3000/TPS | High-speed discrete input sensing |
