Product Introduction
The Honeywell 8C-PAIM01 51454358-175 Low-Level Analog Input Module is designed to handle low-level analog signals with exceptional precision, reliability, and integration capability within Honeywell’s Experion Process Knowledge System (PKS) and C300 Controllers. This module is ideally suited for applications that require high-accuracy signal conversion for weak signals like thermocouples, RTDs, or other low-level sensor signals.
Equipped with high-resolution analog-to-digital conversion, the 8C-PAIM01 ensures accurate reading and processing of low-level signals, making it an essential part of industrial process control systems where signal integrity is paramount. It also supports HART communication, providing advanced diagnostic capabilities and the ability to monitor and maintain field devices remotely. This module is well-suited for industries that require precise temperature and pressure measurements, such as chemical processing, oil and gas, and pharmaceutical production.
With its high input accuracy, multiple input channel options, and robust design, the Honeywell 8C-PAIM01 ensures consistent performance even under harsh industrial conditions, delivering long-term reliability and reduced downtime.
Technical Specifications
| Specification | Details |
|---|---|
| Model | 8C-PAIM01 |
| Part Number | 51454358-175 |
| Manufacturer | Honeywell |
| Input Type | Thermocouple, RTD, Low-level signals |
| Number of Channels | 16 channels (single-ended or differential) |
| Input Resolution | 16-bit |
| Input Accuracy | ±0.1% of full scale |
| HART Communication | Yes (for field device configuration and diagnostics) |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5%–95% non-condensing |
| Power Consumption | < 4 W |
| Mounting | Vertical mounting on DIN Rail |
| Dimensions (H x W x D) | 220 x 120 mm |
| Weight | 0.3 kg |
| Redundancy | Yes, supports fault-tolerant configurations |
| Compliance | CE, UL, FM, CSA, ATEX (depending on configuration) |
Applications
The Honeywell 8C-PAIM01 Low-Level Analog Input Module is tailored for industrial applications where low-level signal processing is critical. Its uses span across various sectors where precision and reliable data acquisition are essential:
-
Chemical Processing Plants
-
Pharmaceutical and Biotechnology Manufacturing
-
Oil and Gas Exploration
-
Power Generation
-
Water and Wastewater Treatment
-
Environmental Monitoring
-
Food and Beverage Processing
-
Mining and Metal Processing
This module excels in systems that rely on thermocouple and RTD sensors for temperature monitoring, as well as low-level pressure and flow measurements in industrial control systems.
Product Advantages
High Resolution
The 16-bit resolution allows for precise processing of low-level analog signals, ensuring accurate data in demanding applications.
Versatile Input Types
Supports various low-level input signals, including thermocouples and RTDs, making it ideal for temperature and pressure measurement systems.
HART Protocol Support
Enables remote diagnostics and configuration of field devices, enhancing ease of maintenance and minimizing downtime.
Built-in Redundancy
Offers fault-tolerant system configurations for continuous operation, essential for critical industrial applications.
High-Precision Signal Conversion
The module’s advanced analog-to-digital conversion ensures minimal signal loss and high data integrity, essential for accurate process control.
Wide Temperature Range
Designed to operate in temperatures ranging from -40°C to +70°C, making it suitable for a broad range of industrial environments.
Compact and Efficient Design
Its small form factor allows for space-saving installation while providing reliable performance in demanding systems.
