Product Introduction
The HIMA F4109 Safety Related Four Channel And Door Module is a high-performance safety module designed to meet stringent industrial safety requirements. This module is an essential component for safety-critical applications, providing four independent safety channels for monitoring and controlling safety-related systems. Additionally, it integrates door monitoring functionality, ensuring safe access control in automated environments.
Engineered for SIL 3 (Safety Integrity Level 3) applications, the F4109 is TÜV-certified and complies with international safety standards. It is widely used in industries such as oil & gas, chemical processing, power generation, and manufacturing, where process safety and personnel protection are paramount.
By incorporating redundant safety mechanisms and fast response times, the HIMA F4109 ensures that hazardous conditions are detected and mitigated immediately. Its compact DIN rail-mounted design allows for easy integration into existing industrial safety systems, making it an ideal choice for applications requiring reliable and scalable safety solutions.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | F4109 |
| Type | Safety Related Four Channel And Door Module |
| Input Voltage | 24V DC ±10% |
| Safety Integrity Level | SIL 3 (TÜV Certified) |
| Number of Safety Channels | 4 Channels |
| Digital Outputs | 8 Safe Outputs |
| Input Type | Potential-Free Contacts |
| Response Time | < 100 ms |
| Communication Interface | HIMA Safety Bus |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 10% to 95% (Non-Condensing) |
| Housing Material | Aluminum/High-Durability Plastic |
| Protection Class | IP20 |
| Dimensions (L x W x H) | 120 x 100 x 75 mm |
| Weight | 0.2 kg |
| Mounting Type | DIN Rail Mountable |
| Certification | IEC 61508, EN 50156, EN 62061, CE, ATEX |
Applications
The HIMA F4109 module is designed for diverse industrial safety applications, particularly in environments requiring high-availability and redundant safety measures. Some of its key applications include:
-
Industrial Automation – Monitoring and controlling emergency shutdown doors, ensuring compliance with safety standards.
-
Power Plants – Enhancing the safety of turbine and generator rooms by regulating access control.
-
Oil & Gas Industry – Used in refineries and offshore platforms to protect personnel from hazardous areas.
-
Chemical Processing – Providing secure access to reactors and process control rooms.
-
Pharmaceutical Manufacturing – Ensuring strict safety procedures in sterile and hazardous environments.
-
Machine Safety – Controlling and monitoring emergency stop switches and safety interlocks.
-
Railway & Transportation – Enhancing safety in train control and signaling systems.
Advantages
-
SIL 3 Certified Safety – Complies with the highest safety integrity level, ensuring reliable operation in critical environments.
-
Four Independent Channels – Allows for multi-zone safety monitoring, reducing the risk of total system failure.
-
Ultra-Fast Response Time (<100 ms) – Ensures immediate action when hazardous conditions are detected.
-
Integrated Door Monitoring – Provides enhanced security and access control for safety-critical areas.
-
Robust Industrial Design – Built to withstand harsh operating conditions, including extreme temperatures and vibrations.
-
Seamless System Integration – Compatible with HIMA Safety Systems, making it easy to integrate into existing safety architectures.
-
DIN Rail Mountable – Simplifies installation and maintenance, minimizing downtime.
-
Redundant Safety Features – Designed for fail-safe operation, reducing the risk of dangerous failures.
Recent News & Updates
-
“HIMA F4109 Enhances Safety in Offshore Oil Rigs” – A major oil & gas company recently deployed the F4109 module to improve access control in hazardous offshore environments.
-
“HIMA Expands Industrial Safety Solutions with the F4109 Module” – The launch of the F4109 has provided industries with an advanced, multi-channel safety monitoring solution.
-
“Power Plants Adopt HIMA F4109 for Enhanced Turbine Safety” – Large power generation facilities have integrated the F4109 for emergency stop and access control systems.
-
“Chemical Plants Upgrade to HIMA F4109 for Increased Operational Safety” – The chemical industry is adopting the F4109 module to monitor process safety and door access points.
Frequently Asked Questions (FAQ)
-
What is the primary function of the HIMA F4109 module?
The F4109 is a safety-related module with four independent channels, designed for monitoring and controlling safety-critical applications, including door monitoring and emergency shutdowns. -
Is the F4109 module suitable for use in hazardous environments?
Yes, the module meets ATEX and IEC 61508 safety certifications, making it suitable for hazardous industrial applications. -
What is the response time of the F4109 module?
The module operates with an ultra-fast response time of less than 100 ms, ensuring rapid action in emergency situations. -
Can the F4109 be integrated into existing safety systems?
Yes, it is fully compatible with HIMA safety control systems and other industry-standard safety architectures. -
How many digital outputs does the F4109 module have?
It features 8 safe digital outputs, providing flexibility for various safety applications. -
What kind of mounting does the module support?
The DIN rail mountable design makes installation simple and efficient. -
What is the operating temperature range of the F4109 module?
It operates within a wide temperature range of -25°C to +70°C, allowing for use in extreme environments. -
Does the F4109 require a separate power supply?
No, it operates on a 24V DC power supply, which is standard for industrial safety systems. -
Is the F4109 module redundant for safety applications?
Yes, it features redundant safety mechanisms to ensure high availability and reliability. -
What industries commonly use the F4109 module?
The module is widely used in oil & gas, power generation, chemical processing, pharmaceuticals, and railway safety applications.
