Product Overview
The HIMA F2 DO 16 01 is a highly reliable and flexible Remote I/O Module designed to meet the rigorous demands of industrial automation. This module is part of the HIMA F2 series, known for its exceptional performance in safety-critical applications, particularly in industries such as oil and gas, chemicals, and process control. It is engineered to provide high accuracy, durability, and ease of integration into safety systems, ensuring operational continuity and safety.
Product Specifications
| Specification | Details |
|---|---|
| Product Type | Remote I/O Module |
| Model Number | F2 DO 16 01 |
| Number of Outputs | 16 |
| Output Type | Digital (Relay Output) |
| Voltage Range | 24 V DC |
| Current Output | 0.5 A per channel |
| Isolation | Galvanic Isolation |
| Response Time | < 1 ms |
| Dimensions (H x W x D) | 207 x 114 x 66 mm |
| Weight | 0.9 kg |
| Temperature Range | -20°C to +60°C |
| Certification | CE, UL, Ex (ATEX) |
| Mounting | DIN Rail |
Applications
The HIMA F2 DO 16 01 is primarily used in safety-critical applications where the reliability of digital outputs is paramount. It is widely used in the following industries:
- Oil and Gas: Ensures safe control of critical equipment, such as valves and actuators, by managing the digital outputs in control systems.
- Chemical Industry: Acts as a control interface for various digital outputs that influence process variables.
- Energy and Power: Vital in controlling power circuits, including safety interlocks and alarms.
- Process Automation: Used for controlling digital devices like solenoid valves and pumps within automation systems.
- Industrial Safety: Forms part of the safety instrumented system (SIS) to ensure safety compliance in hazardous environments.
Advantages
- High Reliability: The HIMA F2 DO 16 01 is built for high availability and fault tolerance, ensuring the safety and efficiency of control systems.
- Flexible Integration: The module can be seamlessly integrated into a wide range of systems, providing flexibility for industrial applications.
- Cost-Effective: By consolidating up to 16 digital outputs in one module, it reduces the need for multiple modules, helping reduce overall system costs.
- Safety Certification: It complies with international standards such as CE, UL, and Ex (ATEX), ensuring it meets rigorous safety and environmental standards.
- Compact Design: With a compact size, the module is perfect for applications where space is limited.
- Ease of Maintenance: The simple design and high-quality components make maintenance and troubleshooting straightforward.
Latest News Titles
- “HIMA Introduces New Safety Modules for Critical Applications”
- “Enhanced Features in HIMA F2 DO Series for Robust Industrial Automation”
- “Safety Excellence: How HIMA F2 DO Modules Are Transforming Process Control”
- “Innovations in Industrial Automation: The Rise of HIMA’s Digital Output Modules”
- “HIMA Expands Product Range with New Digital Output Module for the Energy Sector”
- “HIMA F2 DO 16 01 Set to Revolutionize Oil and Gas Automation”
- “Smart Solutions for Safe Automation: The Role of HIMA F2 Modules”
- “HIMA F2 Series Gains Global Recognition in Safety Systems”
- “HIMA F2 DO 16 01: A Breakthrough in Digital Output Control for Industrial Safety”
- “HIMA’s Role in Shaping the Future of Industrial Automation with the F2 DO Series”
Frequently Asked Questions (FAQ)
-
What is the main function of the HIMA F2 DO 16 01?
- The HIMA F2 DO 16 01 is designed to provide 16 digital output channels for controlling safety-critical devices like actuators and valves in automation systems.
-
What industries can benefit from using the HIMA F2 DO 16 01?
- The module is used in various industries such as oil and gas, chemicals, power, and process automation, especially in safety-critical environments.
-
What is the temperature range of the HIMA F2 DO 16 01?
- The operating temperature range is between -20°C and +60°C.
-
Is the HIMA F2 DO 16 01 certified for hazardous environments?
- Yes, the module is certified with Ex (ATEX) for hazardous locations.
-
How does the HIMA F2 DO 16 01 handle high voltage?
- The module operates at a 24 V DC voltage range and is designed to handle standard industrial voltages for digital outputs.
-
What is the isolation method used in the HIMA F2 DO 16 01?
- The module features galvanic isolation to ensure safety and prevent electrical interference.
-
Can the HIMA F2 DO 16 01 be used in offshore oil and gas applications?
- Yes, the module is suitable for use in offshore oil and gas applications due to its high reliability and ATEX certification.
-
What is the weight of the HIMA F2 DO 16 01 module?
- The module weighs 0.9 kg.
-
How is the HIMA F2 DO 16 01 mounted?
- The module is designed for easy DIN rail mounting.
-
Does the HIMA F2 DO 16 01 support hot swapping?
- Yes, it supports hot swapping, allowing for maintenance without shutting down the system.
