Introduction
The GE IC660BBA105 is a rugged, industrial-grade Current Source Analog Output Module, part of the Genius I/O family from GE Fanuc. This module is built to provide high-precision current outputs in harsh industrial environments, ensuring reliable analog signal control for a wide array of field devices. Specifically designed to deliver consistent and programmable current signals, it serves critical roles in process control, manufacturing automation, and remote I/O applications.
What sets the IC660BBA105 apart is its robust construction, seamless Genius bus integration, and flexibility in configuration. It supports 4 to 20 mA current outputs across 8 analog channels, with each channel capable of being independently configured and calibrated. These features make it a go-to solution for industries requiring scalable and fault-tolerant analog output systems.
Product Specifications
The table below outlines the key technical specifications of the GE IC660BBA105 Analog Output Module:
| Parameter | Specification |
|---|---|
| Product Model | IC660BBA105 |
| Manufacturer | GE Fanuc |
| Type | Current Source Analog Output Module |
| Number of Channels | 8 analog output channels |
| Output Signal Range | 0 to 20 mA (default 4–20 mA range configurable) |
| Output Load Resistance | 0 to 750 Ohms |
| Resolution | 12-bit |
| Power Supply | 5 VDC logic power, 24 VDC output power |
| Isolation | Channel-to-channel and channel-to-ground |
| Diagnostic Features | Open wire detection, module status, fault alert |
| Communication | Genius Bus (GE proprietary I/O network) |
| Mounting | DIN Rail or Panel Mounted |
| Dimensions | 224.4 x 88.9 x 100 mm |
| Weight | 1.43 kg |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% non-condensing |
| Agency Approvals | UL, CSA, CE, FM Class I Div 2 |
Applications
The IC660BBA105 is engineered for precision control across various industrial sectors. Below are some of the primary application areas:
-
Process Automation
For industries such as chemical processing, pharmaceuticals, and food & beverage, where accurate analog signal control is essential. -
Remote I/O Systems
Integrated into distributed control systems where local control units must send analog outputs to field actuators over long distances. -
Energy and Utilities
Applied in the control of current-driven devices like valves, actuators, and variable frequency drives in energy plants and utilities. -
Manufacturing Automation
Used in programmable automation systems controlling flow meters, motors, and pressure regulators. -
HVAC Systems
Analog current outputs used to control dampers, fans, and temperature-regulating valves. -
Water Treatment Facilities
Outputs to modulate pumps, chemical dosing systems, and other process instrumentation equipment.
Advantages
-
High Channel Density
With 8 output channels in a single module, it reduces panel space and simplifies wiring and system design. -
Reliable Output Control
Precise 12-bit resolution ensures accurate current control, critical for sensitive process environments. -
Flexible Configuration
Channels can be independently set up and recalibrated, allowing custom operation across multiple output devices. -
Advanced Diagnostics
Built-in diagnostics assist in identifying channel faults, wiring issues, or module malfunctions without extra tools. -
Genius Bus Integration
Seamless communication with other GE Genius I/O devices, simplifying system-wide coordination. -
Robust Environmental Tolerance
Operates efficiently in high-humidity and high-temperature environments common in industrial installations. -
Isolation Protection
Isolated outputs reduce the risk of electrical interference or cross-channel faults, ensuring safe and consistent performance. -
Compact and Durable Build
Its design enables installation in space-constrained environments while maintaining industrial-grade durability.
FAQ
-
What type of signal does the IC660BBA105 output?
It provides a programmable current output, typically in the 4–20 mA range. -
How many channels are available on the module?
The module has 8 analog output channels. -
Is the module hot-swappable?
No, the IC660BBA105 is not hot-swappable. Power should be turned off before replacement. -
What communication protocol does it use?
It operates on the GE Genius Bus communication protocol. -
Can channels be configured individually?
Yes, each output channel is independently configurable and can be calibrated. -
Is the output isolated?
Yes, the outputs are isolated both from each other and from ground. -
What’s the maximum load resistance per channel?
Each channel supports a load resistance of up to 750 Ohms. -
Does the module support open-wire detection?
Yes, diagnostic features include open-wire detection and fault status monitoring. -
What is the weight of the IC660BBA105?
1.43 kg. -
Can it operate in outdoor environments?
While it has good environmental tolerances, outdoor use would require enclosure in a weatherproof cabinet.
Related Models (Same Series or Application)
| Model | Description | Signal Type | Channels | Mounting |
|---|---|---|---|---|
| IC660BBA100 | Analog Output Module (4-20 mA) | Current Output | 4 | DIN/Panel Mount |
| IC660BBD110 | Analog Input Module (Voltage) | Voltage Input | 8 | DIN/Panel Mount |
| IC660BBD101 | Analog Input Module (Current) | Current Input | 8 | DIN/Panel Mount |
| IC660TBD100 | Discrete Input Module | Digital Input | 32 | DIN/Panel Mount |
| IC660TBA100 | Discrete Output Module | Digital Output | 32 | DIN/Panel Mount |
| IC660BBA104 | High Performance Analog Output Module | Current Output | 8 | DIN/Panel Mount |
Popular GE Fanuc Modules (Same Brand)
| Model | Description | Function | I/O Type | Channels |
|---|---|---|---|---|
| IC693CPU364 | CPU Module with Ethernet | Processor | N/A | N/A |
| IC695CPE330 | PACSystems RX3i CPU | Processor | N/A | N/A |
| IC200ALG264 | VersaMax Analog Output Module | Analog Output | Current/Voltage | 4 |
| IC693MDL645 | 32-Point Digital Output Module | Digital Output | 24VDC Sink | 32 |
| IC200CHS002 | VersaMax Terminal Base | Chassis | N/A | N/A |
| IC697BEM711 | Remote I/O Scanner Module | Communication Module | N/A | N/A |
