Product Overview
The GE IC200PNS001-AC is a PROFINET Scanner (PNS) module designed to interface a remote node of VersaMax I/O modules to a PROFINET IO-Controller. It facilitates the integration of remote I/O systems into PROFINET networks, enabling efficient data exchange between distributed I/O modules and central control systems.
Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | IC200PNS001-AC |
| Manufacturer | Emerson (formerly GE Intelligent Platforms) |
| Series | VersaMax |
| Protocol Supported | PROFINET Version 2.2, Class A I/O Device |
| Ports | 2 x 10/100 Mbps RJ45 Ethernet ports (embedded switch) |
| Power Consumption | 3.0 W |
| Operating Voltage | 24 VDC (nominal) |
| Operating Temperature | 0°C to 60°C |
| Dimensions (H x W x D) | 150 × 90 × 50 mm |
| Weight | 0.4 kg |
| Mounting | DIN rail or panel mount via carrier base (IC200CHSxxx) |
| Firmware Upgrade | USB port for firmware updates (not for permanent connection) |
| Redundant Power Supply | Supports optional redundant power supplies |
| Topology Support | Linear, star, or ring (redundant media) |
| Media Redundancy | Supports Media Redundancy Protocol (MRP) client mode operation |
| Maintenance Mode | Allows servicing of the remote node while maintaining network connections |
Applications
The IC200PNS001-AC module is ideal for applications requiring distributed I/O systems connected to a central PROFINET IO-Controller. Common use cases include:
-
Manufacturing Automation: Connecting remote I/O modules in production lines for real-time data acquisition and control.
-
Process Control Systems: Integrating distributed sensors and actuators into a centralized control system.
-
Building Automation: Managing lighting, HVAC, and security systems through distributed I/O networks.
-
Energy Management: Monitoring and controlling energy consumption across various facilities.
-
Transportation Systems: Implementing distributed control systems for traffic management and signaling.
Advantages
-
Seamless Integration: Easily connects VersaMax I/O modules to PROFINET networks, facilitating integration into existing systems.
-
Flexible Topology: Supports various network topologies, including linear, star, and ring configurations.
-
Redundancy Support: Offers optional redundant power supplies and MRP client mode for enhanced network reliability.
-
Hot Swap Capability: Allows for module replacement without system downtime, ensuring continuous operation.
-
Compact Design: Space-saving form factor suitable for installations with limited space.
-
Easy Configuration: Supports firmware upgrades via USB and configuration using Proficy Machine Edition software.
Frequently Asked Questions (FAQ)
-
What is the purpose of the IC200PNS001-AC module?
-
The IC200PNS001-AC module serves as a bridge between remote VersaMax I/O modules and a central PROFINET IO-Controller, enabling distributed I/O systems to communicate over a PROFINET network.
-
-
How many Ethernet ports does the module have?
-
The module is equipped with two 10/100 Mbps RJ45 Ethernet ports that function as an embedded switch, allowing for flexible network configurations.
-
-
What is the power requirement for the module?
-
The IC200PNS001-AC operates on a 24 VDC nominal power supply and consumes approximately 3.0 W.
-
-
Can the module be used in hazardous locations?
-
The module is not rated for hazardous locations. For installations in such environments, consult the manufacturer’s guidelines for suitable alternatives.
-
-
Is the module hot-swappable?
-
Yes, the IC200PNS001-AC supports hot swapping, allowing for module replacement without system downtime.
-
-
What network topologies are supported?
-
The module supports linear, star, and ring (redundant media) network topologies, providing flexibility in network design.
-
-
Does the module support firmware upgrades?
-
Yes, the module has a USB port for firmware upgrades; however, this port is not intended for permanent connections.
-
-
What is the operating temperature range of the module?
-
The IC200PNS001-AC operates within a temperature range of 0°C to 60°C.
-
-
Can the module be mounted on a DIN rail?
-
Yes, the module can be mounted on a DIN rail or panel mount via the appropriate carrier base.
-
-
Is redundant power supply supported?
-
Yes, the module supports optional redundant power supplies to enhance system reliability.
-
Related Models from the VersaMax Series
| Model Number | Description | Number of Ports | Protocol | Application |
|---|---|---|---|---|
| IC200PNS002-AC | PROFINET Scanner Module | 2 | PROFINET | Similar to IC200PNS001-AC, with additional features. |
| IC200MDL940B | 16-Point Relay Output Module | 16 | Relay | Provides relay outputs for industrial control. |
| IC200MDL750 | 32-Point Discrete Output Module | 32 | Transistor | High-speed digital output for automation. |
| IC200MDL241 | 16-Point Discrete Output Module | 16 | Transistor | Negative logic DC outputs, used in automation. |
| IC200MDL730 | 8-Point Relay Output Module | 8 | Relay | Compact relay output module for small systems. |
| IC200MDL660 | 16-Point Digital Input Module | 16 | Digital | Used for capturing digital input signals in control systems. |
