Product Introduction
The Emerson VE4002S1T2B5 KJ3204X1-BA1 12P3275X022 is a discrete output module designed for the DeltaV Distributed Control System (DCS). This module provides reliable and efficient control of discrete devices within industrial automation systems. With 32 channels of high-side 24 VDC outputs, it is ideal for applications requiring precise on/off control of field devices such as solenoids, relays, and indicators.
Engineered for robustness and versatility, the module ensures seamless integration into DeltaV systems, enhancing operational efficiency and system reliability.
Product Specifications
| Specification | Details |
|---|---|
| Model Number | VE4002S1T2B5 |
| Part Numbers | KJ3204X1-BA1, 12P3275X022 |
| Product Type | Discrete Output Module |
| System Compatibility | Emerson DeltaV DCS |
| Number of Channels | 32 Channels |
| Output Type | High-Side Switching |
| Output Voltage | 24 VDC |
| Output Current per Channel | 100 mA |
| LocalBus Power Rating | 12 VDC at 150 mA |
| Bussed Field Power Rating | 24 VDC at 3.2 A per card |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% RH, non-condensing |
| Shock Resistance | 10g ½ Sinewave for 11 ms |
| Vibration Resistance | 1 mm Peak to Peak from 2 to 13.2 Hz; 0.7g from 13.2 to 150 Hz |
| Airborne Contaminants | ISA-S71.04-1985 Class G3 |
| IP Rating | IP20 |
| Dimensions (L x W x H) | 160 x 130 x 50 mm |
| Weight | 0.181 kg |
| Certifications | CE, UL, CSA, ATEX |
Product Applications
The Emerson VE4002S1T2B5 Discrete Output Module is utilized in various industrial applications, including:
- Manufacturing Automation: Controls machinery and equipment operations.
- Process Control Systems: Manages discrete processes in chemical and petrochemical industries.
- Energy Management: Oversees operations in power generation and distribution systems.
- Water Treatment Facilities: Controls pumps, valves, and other equipment.
- Building Automation: Manages lighting, HVAC systems, and security controls.
Product Advantages
- High Channel Density: Offers 32 output channels, maximizing control capabilities within a compact module.
- Robust Design: Withstands harsh industrial environments with wide operating temperature ranges and resistance to shock and vibration.
- Efficient Power Management: Low power consumption per channel, reducing operational costs.
- Seamless Integration: Fully compatible with Emerson’s DeltaV DCS, ensuring easy installation and configuration.
- Enhanced Reliability: High-side switching design provides improved protection against short circuits and overloads.
Latest News on Emerson VE4002S1T2B5 Discrete Output Module
- “Emerson Enhances DeltaV DCS with New High-Density Discrete Output Modules”
- “Industrial Automation Advances with Emerson’s Latest Discrete Output Solutions”
- “Emerson’s VE4002S1T2B5 Module Boosts Efficiency in Process Control Systems”
- “New Discrete Output Module from Emerson Offers Superior Environmental Resistance”
- “Emerson Introduces Scalable Output Solutions for Modern Manufacturing”
Frequently Asked Questions (FAQ)
-
What is the Emerson VE4002S1T2B5 KJ3204X1-BA1 module used for?
- It is a Discrete Output Module designed for use in Emerson DeltaV DCS, providing reliable control of field devices such as solenoids, relays, and indicators.
-
How many output channels does this module have?
- The VE4002S1T2B5 module has 32 high-side switching discrete output channels.
-
What is the output voltage for this module?
- It operates at 24 VDC output voltage.
-
What is the maximum current per output channel?
- Each output channel can handle up to 100 mA.
-
Is this module compatible with the Emerson DeltaV system?
- Yes, it is fully compatible with the Emerson DeltaV DCS for seamless integration.
-
What are the environmental conditions for operation?
- It can operate within -40°C to +70°C, with a humidity range of 5% to 95% (non-condensing).
-
Does this module include any built-in diagnostic features?
- Yes, it has self-diagnostic capabilities to monitor output status and detect faults.
-
What type of field devices can be controlled using this module?
- It can control solenoids, relays, alarms, indicator lights, and other discrete devices.
-
What certifications does this module have?
- The module is CE, UL, CSA, and ATEX certified, ensuring compliance with international standards.
-
Can this module be used in hazardous environments?
- Yes, when installed properly, it is suitable for hazardous environments, following safety and industry guidelines.
Recommended Related Models
| Model | Description |
|---|---|
| VE4002S1T1B1 | 16-Channel Discrete Output Module, 24 VDC |
| VE4002S1T2B4 | 32-Channel Discrete Output Module, 24 VDC, Low-Side |
| VE4002S1T2B6 | 32-Channel Discrete Output Module, 48 VDC, High-Side |
| VE4002S1T3B1 | 16-Channel Discrete Output Module, 120 VAC |
| VE4002S1T4B2 | 8-Channel Relay Output Module |
| VE4002S1T5B1 | 16-Channel Isolated Discrete Output Module, 24 VDC |
| VE4002S1T6B2 | 8-Channel Discrete Output Module, 48 VDC |
| VE4002S1T7B4 | 32-Channel Discrete Output Module, 120 VAC |
| VE4002S1T8B3 | 16-Channel Discrete Output Module, 230 VAC |
| VE4002S1T9B5 | 32-Channel Discrete Output Module, 230 VAC |
Recommended Popular Models from Emerson
| Model | Description |
|---|---|
| VE4001S2T2B5 | Analog Input Module, 16 Channels |
| VE4003S2B1 | Analog Output Module, 8 Channels |
| VE4005S2B2 | AI Module, 12-Bit Resolution, DeltaV DCS Compatible |
| VE5009 | DeltaV Controller, High-Performance CPU |
| VE4010 | Digital Input Module, 16 Channels, 24 VDC |
| VE4021S2T2B6 | Discrete Input Module, 32 Channels, 120 VAC |
| VE4031S1T3B4 | 16-Channel RTD Input Module |
| VE4042 | Redundant Controller Module, DeltaV DCS |
| VE4050S2T5B1 | HART I/O Card, 8 AI Channels |
| VE4061 | Foundation Fieldbus Interface Module |
