Product Overview
The Emerson KJ3222X1-BA1 12P2532X152 CE4003S2B3 Analog Input Module is a high-performance input module designed to handle analog signal processing in industrial automation systems. Built to meet the demanding requirements of process control and instrumentation, this module is highly reliable in monitoring and controlling real-time processes in a wide variety of industries such as oil and gas, chemical processing, and power generation.
Emerson’s KJ3222X1-BA1 series is designed to convert analog signals from field instruments like pressure transmitters, temperature sensors, and flow meters into digital signals that are understood by the control system. It supports high-precision measurements, ensuring that operators can monitor the performance of critical equipment and systems with great accuracy. The module’s rugged design ensures it can operate reliably under harsh industrial environments, contributing to reduced downtime and increased operational efficiency.
Product Specifications
Below is a detailed table outlining the specifications of the Emerson KJ3222X1-BA1 12P2532X152 CE4003S2B3 Analog Input Module:
| Parameter | Specification |
|---|---|
| Manufacturer | Emerson Automation Solutions |
| Model Number | KJ3222X1-BA1 12P2532X152 CE4003S2B3 |
| Type | Analog Input Module |
| Input Channels | 12 Channels |
| Input Signal Type | 4-20 mA, 0-10V, 1-5V |
| Accuracy | ±0.1% of Full Scale |
| Input Impedance | 250 Ohms |
| Power Supply | 24V DC +/- 10% |
| Operating Temperature | -40°C to +70°C |
| Dimensions (H x W x D) | 80 x 120 x 25 mm |
| Weight | 0.18 kg |
| Mounting Type | Rack-mounted |
| Signal Isolation | Yes, Up to 250 Vrms |
| Compliance | CE, UL, RoHS |
| Bus Communication | HART, Modbus, FOUNDATION Fieldbus |
| Enclosure Material | Polycarbonate (Flame-Retardant) |
| Certifications | ATEX, IECEx, CSA, FM, UL |
| Output Type | Digital signal to Control System |
Product Applications
The Emerson KJ3222X1-BA1 12P2532X152 CE4003S2B3 Analog Input Module is designed for use in a variety of industries where precise analog signal processing is required. Some of the common applications include:
-
Process Control: Used in industries such as petrochemicals, oil & gas, pharmaceuticals, and food & beverage to monitor and control processes such as pressure, flow, temperature, and level.
-
Energy and Utilities: Ensures accurate monitoring of parameters like flow rate, temperature, and pressure in energy production systems, nuclear power plants, and water treatment facilities.
-
Manufacturing: Provides critical real-time data on machine performance and operational conditions to improve efficiency in automated production lines.
-
Building Automation: Used for monitoring HVAC (Heating, Ventilation, and Air Conditioning) systems, ensuring energy efficiency and optimal environmental control.
-
Safety Systems: Integrated into safety systems for emergency shutdowns or alarms triggered by excessive temperature, pressure, or flow changes.
-
Chemical Processing: Enables safe and precise control of chemical reactions, ensuring consistent output and preventing dangerous fluctuations.
Product Advantages
The Emerson KJ3222X1-BA1 12P2532X152 CE4003S2B3 Analog Input Module offers several key advantages:
-
High Accuracy: The module provides an accuracy of ±0.1% of full scale, ensuring high precision for critical industrial measurements.
-
Wide Compatibility: Supports multiple input signal types including 4-20 mA, 0-10V, and 1-5V, allowing it to integrate with a variety of field instruments.
-
Flexible Communication Protocols: Compatible with HART, Modbus, and FOUNDATION Fieldbus for seamless integration with a range of control systems.
-
Wide Operating Temperature Range: Capable of operating in environments from -40°C to +70°C, making it ideal for harsh industrial settings.
-
Compact Design: With dimensions of 80 x 120 x 25 mm, the module is space-efficient and can be easily integrated into existing systems.
-
Certified for Safety: The module is ATEX, IECEx, CSA, and FM certified, ensuring safe operation in hazardous environments.
-
Signal Isolation: Provides signal isolation up to 250 Vrms, preventing electrical interference and ensuring stable signal transmission.
-
Durability: The polycarbonate flame-retardant housing is designed to withstand rugged industrial environments, reducing downtime and maintenance costs.
-
Rack-Mountable: The module is designed for rack mounting, making it easy to incorporate into standard control panels.
-
Global Compliance: Certified to meet global standards including CE, UL, and RoHS for safety and environmental protection.
Latest News
Currently, Emerson Automation Solutions continues to innovate and enhance its product offerings, including the KJ3222X1-BA1 series. Emerson frequently updates its product line to ensure improved performance, increased energy efficiency, and expanded compatibility with emerging technologies. Visit Emerson’s website for the latest product updates, enhancements, and announcements.
Frequently Asked Questions (FAQ)
-
What input signals are supported by the Emerson KJ3222X1-BA1 module?
-
The module supports 4-20 mA, 0-10V, and 1-5V input signals.
-
-
What is the accuracy of the analog input module?
-
The module offers an accuracy of ±0.1% of the full scale.
-
-
Can the module handle high-voltage signals?
-
Yes, the module provides signal isolation up to 250 Vrms, ensuring stable signal transmission in high-voltage environments.
-
-
What are the environmental certifications for the KJ3222X1-BA1 module?
-
The module is certified with ATEX, IECEx, CSA, and FM for use in hazardous environments.
-
-
What is the operating temperature range of the module?
-
The module can operate in temperatures from -40°C to +70°C, making it suitable for a wide range of industrial conditions.
-
-
How many input channels does the KJ3222X1-BA1 have?
-
It has 12 input channels for analog signals.
-
-
Can this module be used in hazardous locations?
-
Yes, it is certified for use in hazardous environments, such as oil and gas or chemical processing plants, with appropriate safety standards.
-
-
What communication protocols are supported by the module?
-
The module supports HART, Modbus, and FOUNDATION Fieldbus protocols.
-
-
Is the module rack-mounted?
-
Yes, the KJ3222X1-BA1 module is designed for rack mounting, facilitating integration into standard industrial control panels.
-
-
What is the weight of the KJ3222X1-BA1 module?
-
The weight of the module is 0.18 kg.
-
