Product Introduction
The Emerson KJ3221X1-BA1 12P2531X132 VE4035S2B1 is a high-performance Analog Output Module designed for Emerson DeltaV Distributed Control Systems (DCS). This module is engineered to convert digital signals into precise analog outputs, allowing accurate control of field devices such as valves, actuators, and variable speed drives.
With robust electrical isolation, fault detection, and redundancy support, the KJ3221X1-BA1 ensures high availability, reliability, and safety in industrial automation. Its compact form factor and DIN rail mounting make it easy to install and integrate into existing DeltaV architectures.
Product Specifications
| Specification | Details |
|---|---|
| Model | KJ3221X1-BA1 (12P2531X132 VE4035S2B1) |
| Type | Analog Output Module |
| System Compatibility | Emerson DeltaV DCS |
| Number of Outputs | 8 Channels |
| Output Type | 4-20 mA Analog Signal |
| Resolution | 16-bit DAC |
| Output Load | 0-750Ω per channel |
| Accuracy | ±0.05% of full scale |
| Power Supply Voltage | 24V DC |
| Current Consumption | 100mA (typical) |
| Signal Isolation | Optical & Galvanic Isolation |
| Redundancy Support | Yes |
| Fault Detection | Open Circuit, Short Circuit |
| Status Indication | LED indicators for status & faults |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Tolerance | 5% to 95% (non-condensing) |
| Dimensions (L x W x H) | 107 x 41 x 105 mm |
| Weight | 0.45 kg |
| Mounting | DIN rail or panel mounting |
| Certifications | CE, UL, ATEX, IECEx |
Applications
The Emerson KJ3221X1-BA1 analog output module is widely used in process control and automation applications, where precise analog signal generation is critical for controlling industrial devices. Some key applications include:
-
Chemical & Petrochemical Processing – Regulates flow control valves, dosing pumps, and chemical reactors for precise process adjustments.
-
Oil & Gas Industry – Ensures accurate modulation of pressure and temperature in pipelines, refineries, and offshore rigs.
-
Power Generation – Controls generator excitation systems, turbines, and fuel injection for efficient power management.
-
Water & Wastewater Treatment – Provides smooth regulation of pump speeds, chemical dosing, and valve positioning.
-
Pharmaceutical Industry – Ensures high-precision control in ingredient mixing, temperature regulation, and pressure control.
-
Food & Beverage Processing – Controls flow rates, mixing speeds, and batch processing in production lines.
-
Factory Automation & Robotics – Enables real-time adjustments to servo motors, actuators, and conveyor systems.
-
Metal & Mining Operations – Supports process automation in smelting, ore processing, and material handling systems.
Advantages
-
High-Precision Analog Output – Delivers 16-bit resolution for accurate control of industrial processes.
-
Multiple Channel Support – Provides 8 independent analog outputs for versatile control applications.
-
Advanced Fault Detection – Built-in diagnostics detect open circuits, short circuits, and output failures.
-
Optical & Galvanic Isolation – Ensures signal integrity and protection against electrical noise.
-
Seamless Integration with DeltaV – Fully compatible with Emerson DeltaV DCS, simplifying system configuration.
-
Rugged Industrial Design – Withstands extreme temperatures, vibrations, and harsh environments.
-
LED Status Indicators – Provides real-time diagnostics and troubleshooting assistance.
-
Redundancy & High Availability – Designed for mission-critical applications requiring continuous operation.
-
Easy Installation & Maintenance – Supports hot-swappable replacement to minimize downtime.
-
Global Certifications – Complies with CE, UL, ATEX, and IECEx standards, ensuring worldwide usability.
