Product Introduction
The Emerson KJ3002X1-BE1 Analog Output Module is a high-performance component designed for seamless integration into Emerson’s DeltaV Distributed Control System (DCS). This module is engineered to convert digital control signals into precise analog outputs, facilitating accurate control of field devices such as valves, actuators, and industrial instrumentation. The KJ3002X1-BE1 ensures robust performance, high-resolution signal output, and excellent reliability in demanding industrial applications.
With its advanced features and high precision, this module plays a crucial role in maintaining stable and efficient process control in industries such as oil and gas, power generation, chemical processing, and manufacturing.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Emerson |
| Model Number | KJ3002X1-BE1 |
| Product Type | Analog Output Module |
| Number of Output Channels | 8 Channels |
| Output Signal Type | 4-20mA or 0-10V Analog Output |
| Resolution | 16-bit |
| Load Resistance | 0-750Ω (for current output) |
| Accuracy | ±0.1% of Full Scale |
| Update Rate | 100ms (typical) |
| Power Supply | 24V DC |
| Power Consumption | 3W |
| Communication Protocol | DeltaV System Bus |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Shock Resistance | IEC 60068-2-27 Compliant |
| Vibration Resistance | IEC 60068-2-6 Compliant |
| Certifications | CE, UL, FCC, CSA, ATEX |
| Dimensions (L x W x H) | 200 x 120 x 60 mm |
| Weight | 0.65 kg |
Product Applications
The KJ3002X1-BE1 Analog Output Module is widely used in various industrial applications where precise analog control is required. Some key application areas include:
- Oil & Gas Industry: Used for controlling actuators and valves in refineries and pipelines.
- Power Generation: Helps regulate turbines and other critical equipment in power plants.
- Chemical Processing: Enables accurate control of chemical dosing and reaction processes.
- Manufacturing Automation: Plays a crucial role in motor speed regulation, temperature control, and pressure adjustments.
- Water & Wastewater Treatment: Used for pump control and chemical dosing systems.
Key Advantages
- High Accuracy & Precision: 16-bit resolution ensures smooth and precise control of analog output signals.
- Robust Industrial Design: Withstands harsh environments with wide operating temperature and humidity ranges.
- Seamless DeltaV Integration: Designed for perfect compatibility with Emerson’s DeltaV system, ensuring easy installation and configuration.
- Reliable and Stable Performance: Low drift and high linearity reduce operational errors.
- Multiple Output Ranges: Supports both voltage and current output, providing flexibility for different industrial applications.
- Fast Response Time: Ensures real-time process adjustments, enhancing efficiency and safety.
- High Safety Standards: Certified for use in hazardous locations with ATEX, CE, and UL certifications.
Latest News & Industry Updates
- Emerson Expands DeltaV System Capabilities with New I/O Modules
- KJ3002X1-BE1: Enhancing Control Performance in Process Industries
- Emerson Introduces Next-Generation Analog Output Modules for Industrial Automation
- How Emerson’s Advanced I/O Modules Improve Efficiency in Power Generation
- DeltaV System Innovations: The Role of High-Precision Analog Output Modules
Frequently Asked Questions (FAQ)
-
What is the function of the Emerson KJ3002X1-BE1 Analog Output Module?
It converts digital signals from the DeltaV system into precise analog outputs for controlling external devices such as actuators and valves. -
What type of output signals does this module support?
The module supports both 4-20mA current output and 0-10V voltage output for flexibility in different applications. -
How many output channels does this module have?
It features 8 analog output channels, allowing multiple devices to be controlled simultaneously. -
Can this module be used in hazardous environments?
Yes, it is ATEX-certified and designed to operate in hazardous industrial locations. -
What is the accuracy level of the KJ3002X1-BE1?
The module provides an accuracy of ±0.1% of full scale, ensuring high-precision signal transmission. -
What is the power supply requirement?
The module operates on a 24V DC power supply with a typical power consumption of 3W. -
Is the module compatible with older DeltaV systems?
Yes, the KJ3002X1-BE1 is backward-compatible with older DeltaV controllers and I/O systems. -
What is the response time of the analog outputs?
The module has a typical update rate of 100ms, ensuring real-time adjustments. -
Does this module require special configuration software?
It is configured using Emerson’s DeltaV system software, which simplifies setup and diagnostics. -
What is the advantage of using a 16-bit resolution in analog outputs?
Provides highly accurate and smooth signal conversion, minimizing errors and ensuring precise control of connected devices.
Recommended Related Models (Same Series or Functionally Similar)
| Model Number | Description | Output Type |
|---|---|---|
| KJ3002X1-BE1 | Analog Output Module (8 channels) | 4-20mA / 0-10V |
| KJ3202X1-BA1 | Digital Output Module | 24V DC |
| KJ3222X1-BA1 | Analog Output Module (4 channels) | 4-20mA |
| KJ3243X1-BB1 | Profibus DP Communication Module | Profibus DP |
| KJ3221X1-BA1 | Analog Input Module | 4-20mA Analog |
| KJ4001X1-BB1 | DeltaV Controller Module | DeltaV Bus |
| KJ3201X1-BA1 | Digital Input Module | 24V DC |
| KJ2003X1-BB1 | Redundant Control Module | DeltaV System |
| KJ3241X1-BA1 | HART Communication Module | HART Protocol |
| KJ1501X1-BB1 | I/O Expansion Module | DeltaV Network |
