Product Introduction
The Emerson 12P3275X022 KJ3204X1-BA1 Discrete Output Module is a high-performance industrial automation module designed for precise control and monitoring of digital signals. As part of Emerson’s renowned Ovation™ Distributed Control System (DCS), this module plays a crucial role in process automation by providing reliable and efficient discrete output functionalities.
The KJ3204X1-BA1 module is used to send on/off control signals to field devices such as actuators, solenoids, relays, and alarms. Engineered for robustness and compatibility, it ensures seamless integration into industrial environments such as power plants, oil and gas facilities, water treatment plants, and manufacturing units.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | 12P3275X022 KJ3204X1-BA1 |
| Brand | Emerson |
| Module Type | Discrete Output Module |
| Number of Outputs | 16 Channels |
| Output Voltage | 24V DC / 120V AC |
| Output Current | 0.5A per channel |
| Response Time | <10 ms |
| Isolation | Optical Isolation |
| Communication Protocol | Ovation™ Network |
| Operating Temperature | -40°C to 70°C |
| Humidity | 5% to 95% non-condensing |
| Mounting Type | DIN Rail or Panel Mount |
| Dimensions (H x W x D) | 160 x 130 x 50 mm |
| Weight | 0.181 kg |
Applications
The Emerson KJ3204X1-BA1 Discrete Output Module is widely applied in multiple industries due to its high reliability and adaptability. Some key applications include:
- Power Generation – Controls power plant auxiliaries such as breakers, fans, and cooling pumps.
- Oil & Gas Industry – Operates solenoids, alarms, and emergency shutdown systems.
- Chemical & Petrochemical Plants – Controls mixing, filling, and safety interlocks.
- Manufacturing & Assembly Lines – Manages conveyor belts, robotic arms, and lighting systems.
- Water & Wastewater Treatment – Controls valve actuators, motorized gates, and alarm systems.
Advantages
The Emerson KJ3204X1-BA1 Discrete Output Module provides several benefits that make it ideal for industrial automation:
- High Reliability – Designed to operate in harsh industrial conditions with minimal downtime.
- Fast Response Time – Ensures real-time control and quick execution of output signals.
- Optical Isolation – Protects control systems from electrical noise and signal interference.
- Energy Efficient – Optimized power consumption for lower operational costs.
- Seamless Integration – Fully compatible with Emerson’s Ovation™ DCS, ensuring easy implementation.
- Robust Construction – Resistant to vibrations, high humidity, and extreme temperatures.
- Scalability – Ideal for both small-scale and large industrial automation systems.
- Secure Data Transmission – Ensures reliable communication with field devices.
