Product Introduction
The ABB DI610 (Part Number: 3BHT300004R1) is a Digital Input Module engineered for ABB’s Advant Controller 410 series and is widely deployed in process automation environments. Designed for high reliability and long operational life, the DI610 provides robust digital signal acquisition and acts as a critical component in Distributed Control Systems (DCS).
Each module offers 16 optically isolated digital input channels, allowing seamless monitoring of binary field signals such as switches, limit sensors, push-buttons, and other discrete devices. The DI610 is built to endure harsh industrial environments while offering precise, interference-immune signal recognition. It interfaces directly with I/O bus systems and integrates easily into both new and legacy ABB automation platforms.
This module is an essential choice for system integrators and engineers focused on building secure, real-time digital input channels within safety-critical or high-availability control architectures.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Name | DI610 Digital Input Module |
| Order Code | 3BHT300004R1 |
| Input Channels | 16 Digital Inputs (optically isolated) |
| Input Voltage | 24 V DC (nominal) |
| Input Voltage Range | 18 to 30 V DC |
| Input Signal Type | Binary (High = 1, Low = 0) |
| Input Delay Time | Typically <5 ms |
| Isolation | Optical isolation per channel |
| Input Current | Typically 7 mA @ 24 V DC |
| Diagnostics | Status and fault indication via system software |
| Connection Type | Screw terminal block |
| Bus Type | Advant Fieldbus 100 |
| Redundancy Support | Yes (when configured) |
| Power Supply Voltage | Supplied via backplane |
| Module Status Indicators | Yes (LEDs per channel) |
| Cooling Requirement | Natural convection |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Relative Humidity | 5% to 95% non-condensing |
| Mounting Type | DIN rail (rack mount module) |
| Protection Rating | IP20 |
| Dimensions (W x H x D) | 40 x 230 x 120 mm |
| Weight | 0.4 kg |
| Certifications | CE, RoHS, UL, CSA |
| System Compatibility | Advant Controller 410/450, Symphony DCI System Six |
Applications
-
Power Plants: Ideal for control systems in thermal, hydro, and nuclear power stations.
-
Petrochemical Plants: Used in monitoring critical discrete inputs from field equipment.
-
Pulp & Paper Industry: Interfaces with machinery control panels and conveyor switches.
-
Water Treatment Plants: Reliable detection of valve positions and limit sensors.
-
Steel Manufacturing: Monitors automation logic for furnaces, rolling mills, etc.
-
Marine & Offshore Systems: Applied in high-availability shipboard automation.
-
Pharmaceutical Manufacturing: Used in cleanroom automation and packaging lines.
-
Process Automation: Suited for broad industrial use within DCS architectures.
Product Advantages
-
High Channel Density: 16 input channels in a compact module format.
-
Rugged & Industrial-Grade: Engineered for continuous operation in demanding environments.
-
Legacy System Compatibility: Supports Advant Controller systems, ensuring long-term value.
-
Fast Response Time: Low-latency input response for time-sensitive operations.
-
LED Indicators: Visual channel status indication simplifies troubleshooting.
-
Safe Isolation: Optical isolation provides electrical separation from field signals.
-
Field-Proven Design: Decades of proven reliability in thousands of installations.
-
Maintenance Friendly: Screw terminals and modular layout ease replacement and wiring.
