Product Overview
The ABB Bailey IPECB11 Power Entry Circuit Breaker is a critical component within the Infi 90 Distributed Control System (DCS), designed to provide reliable overcurrent protection and power distribution for industrial automation applications. This circuit breaker ensures the safe and efficient operation of control systems by managing power input and safeguarding against electrical faults.
Technical Specifications
| Parameter | Specification |
| Model Number | IPECB11 |
| Manufacturer | ABB Bailey |
| Product Type | Power Entry Circuit Breaker |
| System Compatibility | Infi 90, Symphony, Harmony, Network 90 |
| Input Voltage | 120/240 VAC |
| Frequency | 50/60 Hz |
| Current Rating | 20 Amps |
| Dimensions (L×W×H) | 114.3 x 193.04 x 162.56 mm |
| Weight | 2.55 kg |
| Country of Manufacture | Sweden |
Applications
-
Industrial Automation: Provides power protection and distribution in automated manufacturing systems.
-
Process Control Systems: Ensures reliable power entry for critical process control equipment.
-
Distributed Control Systems (DCS): Integral to ABB’s Infi 90, Symphony, and Harmony DCS platforms.
-
Power Management: Manages power input and safeguards against overcurrent in various industrial settings.
Advantages
-
Reliable Protection: Offers dependable overcurrent protection to prevent equipment damage.
-
System Compatibility: Designed to integrate seamlessly with ABB’s Infi 90, Symphony, and Harmony systems.
-
Compact Design: Space-saving form factor facilitates easy installation in control panels.
-
Durable Construction: Built to withstand harsh industrial environments, ensuring longevity.
-
Ease of Maintenance: Modular design allows for straightforward replacement and servicing.
Latest News Headlines
-
“ABB Enhances Industrial Safety with Robust Power Entry Solutions”
-
“Upgrades to ABB’s Infi 90 System Improve Reliability and Efficiency”
Frequently Asked Questions (FAQ)
-
How can I verify if the IPECB11 breaker is functioning properly on-site?
You can check for proper breaker operation by measuring input/output voltage under load and visually inspecting the trip status. If available, review any status LEDs or fault indicators on the associated Infi 90 power chassis.
-
Does the IPECB11 offer field-replaceable components, or must the entire unit be swapped during servicing?
The IPECB11 is designed as a modular unit. In most maintenance scenarios, the complete module is replaced rather than servicing individual internal parts, ensuring reliability and minimizing downtime.
-
What environmental conditions should I avoid when installing the IPECB11?
Avoid high-humidity environments without enclosure sealing, direct exposure to corrosive gases or dust, and ambient temperatures exceeding the recommended operating range (typically 0–60°C).
-
Is the IPECB11 hot-swappable within a live system rack?
No. For safety and to prevent power disturbances or arc flash risks, the IPECB11 should only be replaced when the system is powered down and properly isolated.
-
Can this breaker be integrated into a custom-built control cabinet outside of ABB’s standard systems?
Yes, as long as voltage, current, and mounting specifications are observed. However, optimal integration is achieved within ABB’s Harmony or Infi 90-based architectures.
-
How can I distinguish an original IPECB11 from a third-party replica?
Look for official ABB/BAILEY markings, matching serial and part numbers, and quality of materials. Original modules also come with traceable quality documentation and batch certificates.
-
What happens if the load current slightly exceeds the rated 20A? Will the breaker trip instantly?
The breaker features a time-delay trip curve. Momentary surges may not cause immediate trips, but sustained overloads beyond rated current will trigger protection mechanisms.
-
Is the IPECB11 compatible with modern ABB Symphony Plus platforms?
Yes, it is backward-compatible with several generations of ABB control platforms, including Symphony Plus where legacy modules are still supported in hybrid environments.
-
Is there any visual indication on the IPECB11 to show that it has tripped or requires reset?
Yes. The IPECB11 includes a manual reset toggle or actuator that will physically shift position when the breaker has tripped due to an overload or fault condition.
-
Are there any software diagnostics tools associated with this breaker model?
The breaker itself doesn’t support direct digital diagnostics. However, system-level monitoring through ABB DCS platforms may flag power anomalies related to this module.
