Product Overview
The ABB Bailey IMASI02 is part of the Bailey Distributed Control System (DCS), which is widely used in process automation and control applications. The IMASI02 module is a critical component for automation in industrial processes, offering significant capabilities for input/output (I/O) interfacing in a robust and reliable manner. This module facilitates the seamless integration of various signals and devices into the DCS, ensuring efficient and continuous operation of the control system. The IMASI02 is specifically designed to handle analog signals with precision, supporting the automation of complex industrial processes, while ensuring real-time monitoring and control.
The IMASI02 module is commonly used in industries such as power generation, oil & gas, chemical processing, and manufacturing, where process control and automation are critical to operational safety, efficiency, and performance.
Product Specifications
| Specification | Details |
|---|---|
| Product Type | Analog Input Module |
| Model Number | IMASI02 |
| Input Type | Analog (4-20mA, 0-10V) |
| Output Type | Analog (4-20mA, 0-10V) |
| Input/Output Channels | 8 Analog Inputs/Outputs |
| Voltage Range | 24 V DC |
| Current Consumption | 200 mA (typical) |
| Temperature Range | -20°C to +60°C |
| Dimensions (H x W x D) | 50 x 174 x 250 mm |
| Weight | 0.5 kg |
| Mounting | DIN Rail |
| Certification | UL, CE, CSA, ATEX |
| Isolation | Galvanic Isolation |
| Response Time | 10 ms per channel |
| Accuracy | ±0.1% of full scale |
| LED Indicators | Yes (Status, Error) |
Applications
The ABB Bailey IMASI02 module is used in a wide range of applications where accurate and reliable control of analog signals is essential. Its key applications include:
- Power Generation: In power plants, the IMASI02 module is used to monitor parameters such as temperature, pressure, and flow in critical systems like turbines and boilers.
- Oil & Gas: Used in refining and extraction processes to monitor critical variables such as flow rates, levels, and temperature.
- Chemical Processing: Ensures the continuous measurement and control of chemical processes, such as pH levels, pressure, and flow in reactors.
- Manufacturing: In automated production lines, the IMASI02 module provides precise control over manufacturing processes, including monitoring machinery and raw materials.
- Water Treatment: Used in water treatment plants to measure and control water quality parameters, ensuring safe and efficient operations.
- Food and Beverage: Facilitates the automation of production lines and ensures safe production conditions by monitoring temperature and other variables in real-time.
Advantages
- High Precision: The IMASI02 module provides highly accurate analog signal processing, ensuring that control systems operate precisely, which is crucial for complex industrial processes.
- Galvanic Isolation: The module features galvanic isolation, which ensures safety by preventing electrical interference between the system and external devices.
- Flexible Signal Handling: With support for 4-20mA and 0-10V signals, the IMASI02 can interface with a wide variety of devices and sensors, providing flexibility in system design.
- Compact and Efficient: The module’s compact design allows it to be installed in limited spaces while still offering high functionality.
- Robust Construction: Designed to withstand harsh industrial environments, the IMASI02 module is durable and reliable in high-demand applications.
- Seamless Integration: Easily integrates into existing ABB DCS setups, reducing the time and effort required for system upgrades or expansions.
- Wide Temperature Range: The module operates in a broad temperature range of -20°C to +60°C, making it suitable for use in a variety of environmental conditions.
- Real-Time Monitoring: Provides real-time monitoring and control of critical parameters, enhancing the overall efficiency and safety of industrial processes.
- Compliance with Safety Standards: With certifications such as UL, CE, and ATEX, the IMASI02 is compliant with international safety and quality standards.
- Low Power Consumption: Designed for energy-efficient operation, the IMASI02 helps reduce overall system power consumption, contributing to more sustainable operations.
