Product Overview

The 83SR04 module is utilized for stored-program binary and analog control tasks at the drive, group, and unit control levels. It is suitable for applications such as drive control of unidirectional drives, actuators, solenoid valves, binary function group control (sequential and logic), 3-step control, and signal conditioning. The module is intended for use in connection with the multipurpose processing station and can operate in three different modes: binary control mode (with analog basic functions) with variable cycle time, analog control mode (with binary control) with fixed, selectable cycle time, and signal conditioning mode with fixed cycle time and disturbance bit output. The operating mode is selected by means of function block TXT1, which is the first to appear in the structure. In binary control mode, up to 4 binary function group controls or 4 drive controls, or combinations thereof, can be implemented per module, depending on the module cycle time. In analog control mode, a maximum of 4 analog control loops in the form of 3-step controllers can be implemented per module, depending on the regulating time of the actuator. The module incorporates 4 hardware interfaces to the switchgear and the process.​

Technical Specifications

Applications

The ABB 83SR04 module is widely employed in various industrial sectors due to its flexibility and reliability. Common applications include:​

• Drive Control: Managing unidirectional drives and actuators in industries such as manufacturing and processing.​

• Solenoid Valve Control: Controlling solenoid valves for fluid and gas flow regulation.​

• Binary Function Group Control: Implementing sequential and logic controls within complex industrial processes.​

• 3-Step Control: Executing precise control operations requiring incremental adjustments.​

• Signal Conditioning: Enhancing signal quality for accurate data acquisition and processing.​

Advantages

The ABB 83SR04 module offers several key advantages:

• Versatility: Capable of handling both binary and analog control tasks, accommodating a wide range of industrial applications.​

• High Performance: Features a processing speed of 10 MIPS and 2 MB flash memory for efficient operation.​

• Robust Design: Built to withstand harsh industrial environments with an IP54 environmental rating.​

• Long Service Life: Relay output stages designed for ≥20 million switching cycles, ensuring durability and reliability.​

• Flexible Operating Modes: Supports multiple operating modes to suit various control requirements.​

• Comprehensive I/O Channels: Provides 32 input and 24 output channels for extensive connectivity.

Frequently Asked Questions (FAQ)

1. What is the primary function of the ABB 83SR04 GJR2390200R1210 Control Module?

   • The ABB 83SR04 GJR2390200R1210 is a control module designed for industrial automation systems, providing both binary and analog control functions for managing actuators, solenoid valves, and other control elements within complex industrial processes. ​

2. What are the key technical specifications of this control module?

   • Key specifications include:​

     • Power Supply Voltage: 85–265 VAC

     • Operating Frequency: 400 Hz

     • Communication Protocol: Profinet

     • Processing Speed: 10 MIPS

     • Memory Capacity: 2 MB Flash Memory

     • Input/Output Channels: 32 Inputs, 24 Outputs

     • Environmental Rating: IP54

     • Dimensions: 198 mm (Depth) x 261 mm (Height) x 20 mm (Width)

     • Weight: 0.55 kg

3. In what operating modes can the ABB 83SR04 module function?

   • The module can operate in three distinct modes:​

     • Binary Control Mode: Variable cycle time for binary control functions with analog basic functions.

     • Analog Control Mode: Fixed, selectable cycle time for analog control functions with binary control.

     • Signal Conditioning Mode: Fixed cycle time with disturbance bit output for signal conditioning tasks.

4. What types of applications is this control module suitable for?

   • The ABB 83SR04 module is suitable for various applications, including:​

     • Drive control of unidirectional drives

     • Actuator control

     • Solenoid valve control

     • Binary function group control (sequential and logic)

     • 3-step control

     • Signal conditioning

5. What are the physical dimensions and weight of the module?

   • The module measures 198 mm in depth, 261 mm in height, and 20 mm in width, with a weight of 0.55 kg. ​

6. What is the environmental protection rating of the ABB 83SR04 module?

   • The module has an IP54 environmental rating, indicating protection against dust and water splashes, making it suitable for industrial environments. ​

7. How does the module communicate within an industrial automation system?

   • The ABB 83SR04 module utilizes the Profinet communication protocol, facilitating seamless data exchange within industrial automation systems. ​

8. What is the processing capability of the module?

   • The module features a processing speed of 10 MIPS and is equipped with 2 MB of Flash Memory, ensuring efficient handling of control tasks. ​

9. Is the ABB 83SR04 module compliant with environmental regulations?

   • The module is not RoHS compliant and falls under WEEE Category 5 for small equipment. ​

10. What is the expected service life of the relay outputs in the module?

    • The relay output stages are designed for a service life of ≥20 million switching cycles, ensuring long-term reliability in industrial applications.

Related Models

Popular ABB Models

Frequently Asked Questions (FAQ)

1. What is the primary function of the ABB 83SR04 GJR2390200R1210 Control Module?

   • The ABB 83SR04 GJR2390200R1210 is a control module designed for industrial automation systems, providing both binary and analog control functions for managing actuators, solenoid valves, and other control elements within complex industrial processes. ​

2. What are the key technical specifications of this control module?

   • Key specifications include:​

     • Power Supply Voltage: 85–265 VAC

     • Operating Frequency: 400 Hz

     • Communication Protocol: Profinet

     • Processing Speed: 10 MIPS

     • Memory Capacity: 2 MB Flash Memory

     • Input/Output Channels: 32 Inputs, 24 Outputs

     • Environmental Rating: IP54

     • Dimensions: 198 mm (Depth) x 261 mm (Height) x 20 mm (Width)

     • Weight: 0.55 kg

3. In what operating modes can the ABB 83SR04 module function?

   • The module can operate in three distinct modes:​

     • Binary Control Mode: Variable cycle time for binary control functions with analog basic functions.

     • Analog Control Mode: Fixed, selectable cycle time for analog control functions with binary control.

     • Signal Conditioning Mode: Fixed cycle time with disturbance bit output for signal conditioning tasks.

4. What types of applications is this control module suitable for?

   • The ABB 83SR04 module is suitable for various applications, including:​

     • Drive control of unidirectional drives

     • Actuator control

     • Solenoid valve control

     • Binary function group control (sequential and logic)

     • 3-step control

     • Signal conditioning

5. What are the physical dimensions and weight of the module?

   • The module measures 198 mm in depth, 261 mm in height, and 20 mm in width, with a weight of 0.55 kg. ​

6. What is the environmental protection rating of the ABB 83SR04 module?

   • The module has an IP54 environmental rating, indicating protection against dust and water splashes, making it suitable for industrial environments. ​

7. How does the module communicate within an industrial automation system?

   • The ABB 83SR04 module utilizes the Profinet communication protocol, facilitating seamless data exchange within industrial automation systems. ​

8. What is the processing capability of the module?

   • The module features a processing speed of 10 MIPS and is equipped with 2 MB of Flash Memory, ensuring efficient handling of control tasks. ​

9. Is the ABB 83SR04 module compliant with environmental regulations?

   • The module is not RoHS compliant and falls under WEEE Category 5 for small equipment. ​

10. What is the expected service life of the relay outputs in the module?

    • The relay output stages are designed for a service life of ≥20 million switching cycles, ensuring long-term reliability in industrial applications.

Related Models

Popular ABB Models

Excellent PLC Co., Ltd. has a large number of brand new and original PLC and DCS spare parts, with more than 60 cooperative countries. All products are guaranteed for 1 year and delivered to you by high-quality express. We are committed to using the best products and the most favorable prices to meet the needs and friendship of our customers. We have won the trust of thousands of customers, including these excellent customers.

As for the delivery time, when we receive your order requirements, we will arrange for warehouse personnel to test and verify the products. After you place the order, we will send it to you within 24 hours.
