Product Introduction
The ABB 07DI92 GJR5252400R4101 Digital I/O Module is a high-performance component designed to interface with a wide range of industrial field devices. It is part of the ABB Advant Controller series, which is used extensively in process automation, industrial control systems, and automation technology. The module combines both digital input and output functions, making it a versatile choice for managing various industrial signals such as switches, relays, and status indicators.
This Digital I/O module is designed to be compact, efficient, and highly reliable, providing a seamless solution for industrial environments where real-time data acquisition and control are crucial. With a robust design, the 07DI92 module supports 24V DC digital inputs and outputs, ensuring safe and accurate control for critical applications in industries like energy, oil & gas, water treatment, and manufacturing.
The 07DI92 module integrates seamlessly into ABB’s system architecture, enabling users to extend their control systems while maintaining a high degree of flexibility. It is ideal for both small-scale and large-scale applications, offering users flexibility and performance.
Product Specifications
| Parameter | Specification |
| Product Name | Digital Input/Output Module |
| Model Number | 07DI92-S |
| Ordering Code | GJR5252400R4101 |
| Manufacturer | ABB |
| Series | Advant Controller |
| Number of Digital Inputs | 8 Inputs |
| Number of Digital Outputs | 8 Outputs |
| Input Voltage Range | 24V DC ±20% |
| Output Voltage Range | 24V DC ±20% |
| Input Signal Type | Sink/Source, ON/OFF Logic |
| Output Signal Type | Relay, Transistor Switch |
| Channel Isolation | Optical Isolation between I/O and Internal Bus Logic |
| Input Filtering Time | ~3 ms (Typical) |
| Output Control Method | ON/OFF, Pulse Width Modulation (PWM) |
| Mounting Type | DIN Rail or Rack Mount |
| Power Supply | 24V DC ±20% |
| Operating Temperature Range | 0°C to +60°C |
| Storage Temperature Range | -40°C to +70°C |
| Relative Humidity | 5% to 95% (Non-condensing) |
| Dimensions (W x H x D) | 120 x 140 x 85 mm |
| Weight | 0.59 kg |
| Certification | CE, UL, RoHS |
| EMC Protection | Industrial Grade Immunity |
| LED Diagnostic Indicators | Yes, for each input and output channel |
Applications
The ABB 07DI92 GJR5252400R4101 Digital I/O Module is suitable for a wide range of applications across multiple industries. Below are some of its primary uses:
-
Industrial Automation: The module is used to connect digital field devices such as switches, sensors, and actuators to industrial automation systems. It is widely used in industries like automotive, food & beverage, and consumer goods.
-
Power Generation: The module interfaces with various field devices like relays, status indicators, and safety switches, providing crucial data and control in power plants and electrical grids.
-
Oil & Gas: It is used for controlling pumps, valves, emergency shutdown systems, and other critical infrastructure in the oil and gas industry, ensuring reliable operation even in harsh environments.
-
Water Treatment: The 07DI92 module is employed to control and monitor various digital signals from field devices such as water level sensors, flow meters, and valve actuators in water treatment plants.
-
Manufacturing Automation: In manufacturing environments, the module helps integrate digital sensors and actuators into automated assembly lines, enabling faster and more accurate production processes.
-
Building Automation: It is used to monitor and control digital inputs and outputs from various building systems, such as HVAC, security systems, and lighting control.
Product Advantages
-
Dual Functionality (Digital Inputs/Outputs)
The 07DI92 module combines both input and output functions in one device, reducing the need for multiple modules and simplifying system design. -
High Flexibility
The module supports both sink and source input types, making it compatible with a wide range of digital devices in various industrial setups. -
Compact Design
With its compact size, the module is ideal for applications where space is limited, allowing for easy integration into control cabinets and system panels. -
Optical Isolation for Safety
The use of optical isolation between the I/O channels and the internal system ensures that the module can operate safely even in environments with electrical noise or power surges. -
Quick Diagnostic Feedback
LED diagnostic indicators for each input and output allow operators to quickly assess the operational status of the system, streamlining troubleshooting and maintenance processes. -
Wide Temperature Range
Designed to operate in harsh environments, the 07DI92 module is suitable for use in a wide range of temperatures from 0°C to 60°C, ensuring reliable performance in challenging conditions. -
Cost Efficiency
Combining digital inputs and outputs in a single module reduces overall system complexity and cost, making it an excellent choice for applications that require a high density of I/O in confined spaces. -
Reliable Performance
Built with industrial-grade components, the module delivers high reliability and stability, even in high-vibration and high-electrical-noise environments.
Frequently Asked Questions (FAQ)
-
What is the input voltage range for the 07DI92 module?
→ The input voltage range is 24V DC ±20%. -
Can the 07DI92 module handle both digital inputs and outputs?
→ Yes, it can handle both digital inputs and outputs, providing a versatile solution for industrial applications. -
How many input and output channels does the module have?
→ The 07DI92 module has 8 digital input channels and 8 digital output channels. -
What types of digital signals does this module support?
→ The module supports both sink and source input signals as well as ON/OFF logic. -
What kind of isolation does the module provide?
→ The module features optical isolation between the I/O channels and the internal bus logic to protect against electrical surges. -
How does the module control digital outputs?
→ The module can control digital outputs using ON/OFF logic or Pulse Width Modulation (PWM) for more precise control. -
What is the operating temperature range of the 07DI92 module?
→ The operating temperature range is from 0°C to +60°C. -
Is the module suitable for outdoor applications?
→ While the module is designed for industrial environments, it should be used in controlled, indoor conditions with appropriate environmental protection. -
How is the 07DI92 module mounted?
→ The module can be mounted on DIN rails or in a rack-mount configuration. -
Can this module be used for high-speed control applications?
→ The module is designed for real-time control in industrial environments, but its performance may be limited for extremely high-speed control applications.
Related Models (Same Series or Functionally Similar)
| Model | Description | I/O Configuration | Mounting Type |
| ABB 07DI91-S | Digital Input Module | 16 Inputs | DIN Rail |
| ABB 07DO92 | Digital Output Module | 16 Outputs | DIN Rail |
| ABB 07DC92 | Digital Input/Output Module | 16 Inputs / 16 Outputs | DIN Rail |
| ABB 07DI90 | Digital Input Module | 8 Inputs | DIN Rail |
| ABB 07DI94 | Digital Input Module | 16 Inputs | DIN Rail |
| ABB 07AI92 | Analog Input Module | 16 Inputs | DIN Rail |
Popular ABB Models (Widely Used Industrial Modules)
| Model | Description | Module Type | Key Application |
| ABB PM864AK01 | High-Performance Controller | CPU | Centralized Automation |
| ABB DI810 | Digital Input Module | Digital Input | Sensors and Actuators |
| ABB DO810 | Digital Output Module | Digital Output | Actuators and Relays |
| ABB AI810 | Analog Input Module | Analog Input | Measurement and Control |
| ABB CI854AK01 | PROFIBUS Communication Module | Interface | Fieldbus Communication |
| ABB TU810V1 | Terminal Unit for S800 I/O Modules | Terminal Block | Signal Interfacing |
